Selva PORTOFINO 80 Каталог запчастей онлайн [9/59] 201940
![Selva PORTOFINO 80 Каталог запчастей онлайн [9/59] 201940](/views2/1240431/page9/bg9.png)
Pos.
Ref. No
Q.tà
Q.ty
N. Codice
Part No
Denominazione Name of part
GRUPPI
GROUPS
1 1599460 Registro e supporto rullino Pin register and support
( Pos. 19-20-21-22-23 ) ( Pos. 19-20-21-22-23 )
1 1533865 Serie decalco capote " St.Tropez 40 XS " Hood decal set " St.Tropez 40 XS "
1 1533866 Serie decalco capote " St.Tropez 40 XS " M.A. Hood decal set " St.Tropez 40 XS " M.A.
1 1533950 Serie decalco capote " St.Tropez 50 XS " Hood decal set " St.Tropez 50 XS "
1 1533951 Serie decalco capote " St.Tropez 50 XS” M.A. Hood decal set " St.Tropez 50 XS "M.A.
1 1534050 Serie decalco capote " St.Tropez 55 HP" Hood decal set " St.Tropez 55 HP "
1 1534051 Serie decalco capote " St.Tropez 55 HP" M.A. Hood decal set " St.Tropez 55 HP "M.A.
1 1533861 Serie decalco capote " St.Tropez" 60 HP Hood decal set " St.Tropez "60 HP
1 1533862 Serie decalco capote " St.Tropez" 60 HP M.A. Hood decal set " St.Tropez "60 HP M.A.
1 1534060 Serie decalco capote " Portofino 70 HP" Hood decal set " Portofino 70 HP"
1 1534061 Serie decalco capote " Portofino 70 HP" M.A. Hood decal set " Portofino 70 HP" M.A.
1 1533801 Serie decalco capote " Portofino 80 HP" Hood decal set " Portofino 80 HP"
1 1533802 Serie decalco capote " Portofino 80 HP" M.A. Hood decal set " Portofino 80 HP" M.A.
28 1 1504420 Capote completa di decalco Complete Hood with decal
"St.Tropez 40 XS” "St.Tropez 40 XS"
(da pos 19 a 32+42 + da pos.47 a 53) (from pos 19 to 32+42 + from pos. 47 to 53)
28 1 1504425 Capote completa di decalco Complete Hood with decal
"St.Tropez 40 XS” M.A. "St.Tropez 40 XS" M.A.
(da pos 19 a 32+42+43 + da pos.47 a 53) (from pos 19 to 32+42+43 + from pos. 47 to 53)
28 1 1504430 Capote completa di decalco Complete Hood with decal
"St.Tropez 50 XS” "St.Tropez 50 XS”
(da pos 19 a 32+42 + da pos.47 a 53) (from pos 19 to 32+42 + from pos. 47 to 53)
28 1 1504435 Capote completa di decalco Complete Hood with decal
"St.Tropez 50 XS” M.A. "St.Tropez 50 XS" M.A.
(da pos 19 a 32+42+43 + da pos.47 a 53) (from pos 19 to 32+42+43 + from pos. 47 to 53)
28 1 1504440 Capote completa di decalco Complete Hood with decal
"St.Tropez 55 " "St.Tropez 55 "
(da pos 19 a 32+42 + da pos.47 a 53) (from pos 19 to 32+42 + from pos. 47 to 53)
28 1 1504445 Capote completa di decalco Complete Hood with decal
"St.Tropez 55 " M.A. "St.Tropez 55 " M.A.
(da pos 19 a 32+43 + da pos.47 a 53) (from pos 19 to 32+43 + from pos. 47 to 53)
28 1 1504450 Capote completa di decalco Complete Hood with decal
"St.Tropez 60 HP" "St.Tropez 60 HP"
(da pos 19 a 32 + da pos.47 a 53) (from pos 19 to 32 + from pos. 47 to 53)
28 1 1504455 Capote completa di decalco Complete Hood with decal
"St.Tropez 60 HP" M.A. "St.Tropez 60 HP" M.A.
(da pos 19 a 32+43 + da pos.47 a 53) (from pos 19 to 32+43 + from pos. 47 to 53)
28 1 1504460 Capote completa di decalco Complete Hood with decal
"Portofino 70 HP " "Portofino 70 HP"
(da pos 19 a 32+43 + da pos.47 a 53) (from pos 19 to 32+43 + from pos. 47 to 53)
28 1 1504465 Capote completa di decalco Complete Hood with decal
"Portofino 70 HP " M.A. "Portofino 70 HP" M.A.
(da pos 19 a 32+43 + da pos.47 a 53) (from pos 19 to 32+43 + from pos. 47 to 53)
28 1 1504470 Capote completa di decalco Complete Hood with decal
"Portofino 80 HP " "Portofino 80 HP"
(da pos 19 a 32 + da pos.47 a 53) (from pos 19 to 32 + from pos. 47 to 53)
28 1 1504475 Capote completa di decalco Complete Hood with decal
"Portofino 80 HP " M.A. "Portofino 80 HP" M.A.
(da pos 19 a 32+43 + da pos.47 a 53) (from pos 19 to 32+43 + from pos. 47 to 53)
