![TSC TE300 [8/40] Product features](/views2/1244105/page8/bg8.png)
2
1.2 Product Features
1.2.1 Printer Standard Features
The printer offers the following standard features.
Product standard feature
TE200
(203 dpi
model)
TE300
(300 dpi
model)
Thermal transfer printing
○ ○
Direct thermal printing
○ ○
Plastic
○ ○
Gap sensor
○ ○
Reflective, full-range moveable black mark sensor
○ ○
Ribbon sensor
○ ○
Head open sensor
○ ○
USB 2.0 (hi-speed) interface
○ ○
16 MB DRAM memory
○ ○
8 MB Flash memory
○ ○
SD card reader (R
eserve a PIN connector for updating
firmware by card when maintenance.)
- -
One button for feed and pause
○ ○
One LED indicator for 3 colors
○ ○
Standard industry emulations right out of the box including
Eltron
®
and Zebra
®
language support
○ ○
Internal 8 alpha-numeric bitmap fonts
○ ○
Fonts and bar codes can be printed in any one of the four
directions (0, 90,180, 270 degrees)
○ ○
Internal Monotype Imaging® true type font engine with one
CG Triumvirate Bold Condensed scalable font
○ ○
Downloadable fonts from PC to printer memory
○ ○
Downloadable firmware upgrades
○ ○
