Robert Bosch Hausgeräte GmbH 7

Emptying the pulp container and filter

Fig. C

Empty the pulp container before

the pulp

reaches the edge of the filter tray

Switch off the appliance:

 Move the switch to 0/off.

 To remove the pulp container, take hold

of it with the recessed grip and swivel out.

Before continuing to operate the appliance,

re-insert the pulp container.

Empty the filter if

– the motor speed drops significantly,

– the juice becomes thick,

– the appliance begins to vibrate noticeably.

Recommendation: Empty the pulp container

and filter at the same time.

Important!

If juice has run under the filter tray, immediately

remove with a damp cloth.

Dismantling the appliance

oáëâ=çÑ=ÉäÉÅíêáÅ=ëÜçÅâ>

_ÉÑçêÉ=ïçêâáåÖ=çå=íÜÉ=~ééäá~åÅÉI=~äï~óë=éìää=

çìí=íÜÉ=ã~áåë=éäìÖK

Fig. D

 Switch off the appliance and pull out

the mains plug.

 Wait until the motor stops

(approx. 10–12 sec.).

 Remove the pusher and pulp container.

 Pull both lower catches outwards.

Then lift the catches off the lugs on the lid.

 Remove the cover.

 Lift the filter tray with both hands and take

out of the motor unit.

 Take the filter out of the filter tray.

Cleaning and servicing

oáëâ=çÑ=ÉäÉÅíêáÅ=ëÜçÅâ>

kÉîÉê=áããÉêëÉ=íÜÉ=ãçíçê=ìåáí=áå=ï~íÉê=~åÇ=

åÉîÉê=ÜçäÇ=ìåÇÉê=êìååáåÖ=ï~íÉê>

t~êåáåÖ>

pìêÑ~ÅÉë=ã~ó=ÄÉ=Ç~ã~ÖÉÇK=

aç=klq=ìëÉ=~Äê~ëáîÉ=ÅäÉ~åáåÖ=~ÖÉåíëK=

 First clean the filter with the brush,

then rinse under running water or wash

in the dishwasher.

 Wipe the motor unit with a damp cloth,

if required use a little washing-up liquid.

Dry the motor unit immediately.

 All other parts are dishwasher-proof.

Discoloured plastic parts (e.g. caused

by carrots, beetroot) can easily be removed

with a few drops of vegetable oil.

Put parts in the dishwasher (provided they are

dishwasher-safe).

Replacing the filter

Replace the filter at the first signs of wear

or damage in order to prevent any risk

of breakage. If the appliance is used daily,

the filter should be replaced after approx.

5years.

Disposal

This appliance has been identified

in accordance with the European

directive 2002/96/EG on Waste

Electrical and Electronic Equipment –

WEEE. The Directive paves the way

for effective EU-wide withdrawal and

utilization of waste appliances.

Please ask your dealer or inquire at your local

authority about current means of disposal.

Guarantee

The guarantee conditions for this appliance

are as defined by our representative in the

country in which it is sold. Details regarding

these conditions can be obtained from the

dealer from whom the appliance was

purchased.

The bill of sale or receipt must be produced

when making any claim under the terms of this

guarantee.

Subject to alterations.
