Installation Manual
EMS 1.9R
4
1. Select Installer Switch 27
2. Press buttons 1 and 2 together to enter the RPM learning mode and start the 1minute
timer.
3. The siren will beep 3 times and the indicators will flash 3 times to indicate that the learning
mode has been entered and you have 1minute to start the engine.
4. Start the engine using the ignition key and the alarm system will monitor both the crank
input and the Engine RPM signal.
5. Once the engine has started, the system should wait until 5seconds after the start motor has
been turned off and then learn the frequency (period) of the RPM signal.
6. Once the RPM Signal has been learnt, the system should automatically exit learning mode
beeping the siren unit and flashing the indicators 3 times to indicate that the RPM signal
has been learnt. The system should return to the Installer Software Switch Table at switch
27 (you can use the override switch to move up and down the installer switches as normal)
Notes:
 If you tried to start the car during RPM learning mode and the engine does not start,
then the 1minute learning timer should be reset when the starter motor is switched off.
 If the system remains in learning mode for 1minute without a (a further) attempt to start
the vehicle being made, the system will exit RPM learning mode, beep the siren and
flash the indicators 4 times and return to Installer software switches at switch position
27.
 If the system reads an engine RPM signal but is unable to learn the frequency of the
signal, the system should exit learning mode 1minute after the engine was started and
return to installer switch 27 beeping the siren and flashing the indicators 5 times to
indicate that the signal could not be learnt.
 RPM/Tachometer Remote Start can not be used unit an Idle Engine RPM signal has
been taught to the system – i.e. you must select switch 27 and complete the procedure
above with a 3 flash/beep confirmation being given by the system before Remote Start
will function.
** Increasing the Engine Crank Time when using RPM/Tachometer Engine Monitoring (Switch
28)
In case the engine does not start reliably, installer switch 28 can be used to slighting increase
the engine cranking time. Each time the setting of Switch 28 is increased, the cranking time
of the engine will be changed by the duration of one engine RPM signal pulse. The actual
increase in cranking time will be dependant upon the idle RPM of the engine but will be
approximately 30100mS.
When switch 28 is selected, the LED will fast flash to indicate the current setting of the
switch. The LED will flash once if the setting is one, twice if the setting is two etc. The flash
sequence will repeat with a 3 second gap (LED off) for as long as switch 28 is selected.
Автомобильная охранная система “MONGOOSE” Модель EMS 1.9R
17
РУССКИЙ
Проверка системы
1. Подсоединить аккумулятор автомобиля.
2. Проверить следующие устройства и режимы:
постановка/снятие с охраны;
тихая постановка/снятие с охраны;
паника;
срабатывание на шоксенсор и дополнительные датчики;
двушаговое снятие с охраны»
срабатывание при открывании всех дверей, капота, багажника;
отсутствие срабатывания концевиков капота/багажника при колебании крышек
капота/багажника;
работа кнопки аварийного отключения;
управление центральным замком;
управление дополнительными каналами (если подключены);
автопостановка, перепостановка (защита от случайного снятия с охраны);
Valet режим;
Радиус действия брелоков;
Блокировка двигателя.
Работа системы управления запуском двигателя.
