10
ASUS STRIX Sound Card Series User Manual
English
No.
Items Description
8.
Output Select /
Volume Control
Tab Tab to select output source between the
headphone and speaker.
Long
Press
Long press to set the selected output
source to mute.
Turn Turn the knob clockwise or anti-clockwise to
adjust volume level.
[Custom
Mode]:
Tab
CUSTOM MODE (In conjunction with
STRIX RAID MODE)
Tab the knob to turn on/off a selected effect.
Note: This control knob is used in
conjunction with the Strix RAID key.
When Strix RAID Mode is selected,
this goes into a custom mode.
[Custom
Mode]:
Turn
CUSTOM MODE (In conjunction with
STRIX RAID MODE)
Turn the knob clockwise or anti-clockwise to
adjust intensity level of a selected effect.
9. LED Indicators
LED indicator that displays intensity level of volume or
effects.
10.
Output Source LED
Indicator
LED indicator that displays selected output device.
Note: When the device is mute, the LED turns red.
11. STRIX RAID Mode
This is a programmable key that can customize and
lock a special effect from the Sonic Studio so that you
can control and adjust effects spontaneously in game.
Press on/off to enable/disable Custom Mode. The
LED turns orange to indicate that the Custom Mode is
enabled.
To set up this key, please go to the Sonic Studio and
select an effect to lock the Strix RAID Mode.
Now you can use the knob to enable/disable an effect,
as well as adjust the intensity level of the effect.
12.
Headphone Output
Port
Connect your headphone to this port.
13. Microphone Input Port
Connect your external PC microphone to this 3.5mm
jack for voice input.
14.
Kensington
®
Security
Slot
Insert kensington lock to lock the device.
15. Box link Connect Strix control box directly to this port.
