Asus Strix Soar [17/27] Connecting stereo headphones
![Asus Strix Soar [17/27] Connecting stereo headphones](/views2/1256087/page17/bg11.png)
17
ASUS STRIX Sound Card Series User Manual
English
4.4 Connecting stereo headphones
4.4.1 Connecting Stereo Headphones
No. Items Description
1. Front Out The Headphone Out Port has a built-in high-quality
amplier to drive headphones. Please connect your
stereo headphones directly to this jack.
Side+
S/PDIF Out
Mic/Line-in
Headphone
Front
Box Link
Rear
Center
1
