- 6 -

RESIDUAL RISKS

- OVERTURNING:positiontheweldingmachineonahorizontalsurfacethatis

abletosupporttheweight:otherwise(e.g.inclinedorunevenoorsetc.)there

isdangerofoverturning.

- IMPROPER USE:it is hazardous to use the welding machine for any work

otherthanthatforwhichitwasdesigned(e.g.de-icingmainswaterpipes).

- MOVING THE WELDING MACHINE: Always secure the gas bottle, taking

suitableprecautionssothatitcannotfallaccidentally(ifused).

- Donotusethehandletohangtheweldingmachine.

The safety guards and moving parts ofthecoveringofthewelding machine

andofthewirefeedershouldbeintheirproperpositionsbeforeconnectingthe

weldingmachinetothepowersupply.

WARNING!Anymanualoperationcarriedoutonthemovingpartsofthewire

feeder,forexample:

- Replacingrollersand/orthewireguide;

- Insertingwireintherollers;

- Loadingthewirereel;

- Cleaningtherollers,thegearsandtheareaunderneaththem;

- Lubricatingthegears.

SHOULD BE CARRIED OUT WITH THE WELDING MACHINE SWITCHED OFF

ANDDISCONNECTEDFROMTHEPOWERSUPPLYOUTLET.

2.INTRODUCTIONANDGENERALDESCRIPTION

This welding machine is a source of current for arc welding, made specically for MAG

welding carbon steel or weak alloys with CO

protective gas or Argon/CO

mixes,

using full or core electrode wires.

It is also ideal for MIG welding stainless steel with Argon gas containing + 1-2%

oxygen, aluminium and CuSi

, CuAl

(brazing) with Argon gas, using electrode wires

that are suitable for the workpiece to be welded.

Suitable core wires can also be used without Flux protection gas, adapting the polarity

of the torch to what is indicated by the wire producer.

SYNERGIC operation guarantees fast and easy welding parameter setting, always

guaranteeing high arc control and welding quality (One Touch Technology).

It is particularly suitable for light metalwork fabrication and in body shops, for welding

galvanized plates, high stress stainless steel and aluminium.

2.1MAINCHARACTERISTICS

- Synergic (automatic) or manual operation;

- 17 pre-set synergic curves;

- Wire speed, welding voltage and welding current shown on an LCD screen;

- 2T, 4T and spot operation selection;

- Adjustments: wire up slope, electronic reactance, wire burn-back time, post gas;

- Polarity change for GAS MIG-MAG/BRAZING welding or NO GAS/FLUX;

- Thermostatic safeguard;

- Protection against accidental short-circuits caused by contact between torch and

earth;

- Protection against irregular voltage (power supply voltage too high or too low);

2.2STANDARDACCESSORIES

- torch;

- return cable complete with earth clamp.

2.3OPTIONALACCESSORIES

- Argon bottle adapter;

- Trolley;

- Self darkening helmet;

- MIG MAG welding kit.

3.TECHNICALDATA

3.1DATAPLATE

The most important data regarding use and performance of the welding machine are

summarised on the rating plate and have the following meaning:

Fig.A

1- EUROPEAN standard of reference, for safety and construction of arc welding

machines.

2- Symbol for internal structure of the welding machine.

3- Symbol for welding procedure provided.

4- Symbol S: indicates that welding operations may be carried out in environments

with heightened risk of electric shock (e.g. very close to large metallic volumes).

5- Symbol for power supply line:

1~ : single phase alternating voltage;

3~ : 3-phase alternating voltage.

6- Protection rating of the covering.

7- Technical specications for power supply line:

- U

: Alternating voltage and power supply frequency of welding machine (allowed

limit ±10%).

- I

1max

: Maximum current absorbed by the line.

- I

1eff

: effective current supplied.

8- Performance of the welding circuit:

- U

: maximum no-load voltage (open welding circuit).

- I

: current and corresponding normalised voltage that the welding machine

can supply during welding.

- X : Duty cycle: indicates the time for which the welding machine can supply the

corresponding current (same column). It is expressed as %, based on a 10 min.

cycle (e.g. 60% = 6 minutes working, 4 minutes pause, and so on).

If the usage factors (on the plate, referring to a 40°C environment) are exceeded,

the thermal safeguard will trigger (the welding machine will remain in standby

until its temperature returns within the allowed limits).

- A/V-A/V : shows the range of adjustment for the welding current (minimum

maximum) at the corresponding arc voltage.

9- Manufacturer’s serial number for welding machine identication (indispensable for

technical assistance, requesting spare parts, discovering product origin).

10-

: Size of delayed action fuses to be used to protect the power line.

11-Symbols referring to safety regulations, whose meaning is given in chapter 1

“General safety considerations for arc welding”.

Note: The data plate shown above is an example to give the meaning of the symbols

and numbers; the exact values of technical data for the welding machine in your

possession must be checked directly on the data plate of the welding machine itself.

3.2OTHERTECHNICALDATA

-WELDINGMACHINE:seetable1(TAB.1)

-TORCH:seetable2(TAB.2)

Theweldingmachineweightisshownintable1(TAB.1).

4.DESCRIPTIONOFTHEWELDINGMACHINE

4.1CONTROLDEVICES:ADJUSTMENTANDCONNECTION.

4.1.1WELDINGMACHINE(Fig.B)

Atthefront:

1- Control panel (see description).

2- Cable and welding torch.

3- Cable and earth clamp.

Attheback:

4- Main ON/OFF switch.

5- Shielding gas hose connector.

6- Power supply cable.

Inthereelspace:

7- Positive terminal (+).

8- Negative terminal (-).

N.B.PolarityinversionforFLUXwelding(nogas).

4.1.2WELDINGMACHINECONTROLPANEL(Fig.C)

1- Adjustment of the welding power (synergic operation) or of the wire feed speed

(manual operation). Press the knob to select either SYNERGIC or MANUAL

operation.

2- Adjustment of the arc length (synergic operation) or of the welding voltage (manual

operation). Press the knob to access the various welding machine settings menu;

3- LCD display.

5.INSTALLATION

WARNING! ALL INSTALLATION OPERATIONS AND ELECTRICAL

CONNECTIONS MUST ALWAYS BE CARRIED OUT WITH THE WELDING

MACHINESWITCHEDOFFANDDISCONNECTEDFROMTHEPOWERSUPPLY.

THEELECTRICCONNECTIONSMUSTONLYBECARRIEDOUTBYEXPERTOR

QUALIFIEDTECHNICIANS.

Return cable-clamp assembly

Fig.D

5.1POSITIONINGTHEWELDINGMACHINE

Choose the place where the welding machine is to be installed so that there are no

obstructions to the cooling air inlets and outlets; at the same time make sure that

conductive dust, corrosive vapours, humidity etc. cannot be drawn into the machine.

Leave at least 250 mm of free space all around the welding machine.

WARNING! Position the welding machine on a level surface with

sufcient load-bearing capacity, so that it cannot be tipped over or shift

dangerously.

5.2CONNECTIONTOTHEMAINPOWERSUPPLY

- Before making any electrical connection, check the rating plate data on the welding

machine to make sure they correspond to the voltage and frequency of the available

power supply where the machine is to be installed.

- The welding machine must be connected only and exclusively to a power supply with

the neutral conductor connected to earth.

- To guarantee protection against indirect contact use the following types of residual

current devices:

- A type (

) for single-phase machines.

- In order to satisfy the requirements of the EN 61000-3-11 (Flicker) standard we

recommend connecting the welding machine to the interface points of the main

power supply that have an impedance of less than Zmax = 0.25 ohm.

- The IEC/EN 61000-3-12 Standard does not apply to the welding machine.

If the welding machine is connected to an electrical grid, the installer or user must

make sure that the machine can indeed be connected (if necessary, consult the

company that manages the electrical grid).

5.2.1Plugandoutlet

Connect the power supply plug to a mains socket tted with fuses or an automatic

circuit-breaker; the corresponding earth terminal should be connected to the (yellow-

green) earth conductor of the power supply. Table 1 (TAB. 1) shows the recommended

delayed fuse sizes, in amps, for the main supply, which have been chosen according

to the maximum rated current output from the welding machine, and to the nominal

power supply voltage.

WARNING! Non-compliance with the above regulations renders the

manufacturer’ssafetysystem(classI)inefcient,withresultingseriousrisksto

people(e.g.electricshock)andthings(e.g.re).

5.3WELDINGCIRCUITCONNECTIONS

WARNING! BEFORE CARRYING OUT THE FOLLOWING

CONNECTIONSMAKESURETHATTHEWELDINGMACHINEISSWITCHEDOFF

ANDDISCONNECTEDFROMTHEPOWERSUPPLY.

Table 1 (TAB. 1) shows the recommended sizes of the welding cables (in mm

according to the maximum current output from the welding machine.
