English | 17
Bosch Power Tools 1 609 92A 142 | (10.2.15)
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, until
19 April 2016: 2004/108/EC, from 20 April 2016 on:
2014/30/EU, 2006/42/EC including their amendments and
complies with the following standards:
EN 60745-1, EN 60745-2-5.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY
Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 10.02.2015
Assembly
Battery Charging
Use only the battery chargers listed on the accessories
page. Only these battery chargers are matched to the lith-
ium-ion battery of your power tool.
Note: The battery supplied is partially charged. To ensure full
capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.
The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.
The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.
Do not continue to press the On/Off switch after the
machine has been automatically switched off. The bat-
tery can be damaged.
Observe the notes for disposal.
Removing the battery (see figure A)
The battery 3 is equipped with two locking levels that should pre-
vent the battery from falling out when pushing the battery un-
locking button 17 unintentionally. As long as the battery is insert-
ed in the power tool, it is held in position by means of a spring.
– To remove the battery 3, press the battery unlocking but-
ton 17 and pull the battery upward out of the power tool.
Do not exert any force.
Dust/Chip Extraction
Before any work on the power tool, remove the battery.
Dusts from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dusts can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dusts, such as oak or beech dust, are considered
as carcinogenic, especially in connection with wood-treat-
ment additives (chromate, wood preservative). Materials
containing asbestos may only be worked by specialists.
– As far as possible, use a dust extraction system suitable
for the material.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the
materials to be worked.
Prevent dust accumulation at the workplace. Dusts can
easily ignite.
External Dust Extraction (see figure B)
–Insert a vacuum hose 18 (accessory) into the vacuum con-
nection 4. Connect the vacuum hose 18 to a vacuum clean-
er (accessory). An overview for connecting to a vacuum
cleaner can be found at the end of these instructions.
The vacuum cleaner must be suitable for the material being
worked.
When vacuuming dry dust that is especially detrimental to
health or carcinogenic, use a special vacuum cleaner.
Mounting/Replacing the Saw Blade
Before any work on the power tool, remove the battery.
When mounting the saw blade, wear protective gloves.
Danger of injury when touching the saw blade.
Only use saw blades that correspond with the charac-
teristic data given in the operating instructions.
Do not under any circumstances use grinding discs as
the cutting tool.
Selecting a Saw Blade
An overview of recommended saw blades can be found at the
end of this manual.
Removal of the Saw Blade (see figure C)
For changing the cutting tool, it is best to place the machine
on the face side of the motor housing.
– Press the spindle lock button 19 and keep it pressed.
The spindle lock button 19 may be actuated only when
the saw spindle is at a standstill. Otherwise, the power
tool can be damaged.
–With the Hex key 24, unscrew the clamping bolt 23 turning
in rotation direction .
– Tilt back the retracting blade guard 9 and hold firmly.
– Remove the clamping flange 22 and the saw blade 8 from
the saw spindle 20.
Mounting the Saw Blade (see figure C)
For changing the cutting tool, it is best to place the machine
on the face side of the motor housing.
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
OBJ_BUCH-1889-002.book Page 17 Tuesday, February 10, 2015 2:37 PM
