![Kenwood KDC-W4531 [29/38] Parts list](/views2/1263108/page29/bg1d.png)
29
KDC-W4031/W4031Y/W409/W409Y
KDC-W431GY/W4531/W4531Y/WF431A
Indicates safety critical components.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
PARTS LIST
CD PLAYER UNIT (X32-5500-00)
E : KDC-W4531 E1 : KDC-W4031 E2 : KDC-W409 E3 : KDC-W431GY E6 : KDC-WF431A
E7 : KDC-W4531Y E8 : KDC-W4031Y E9 : KDC-W409Y
(E : Europe K : North America M : Other Areas W : Without Europe)
D52-54 B30-1533-05 LED (PG)
EE1E2
D52-54 B30-1533-05 LED (PG)
E3E7E8
D52-54 B30-1533-05 LED (PG) E9
D61-65 B30-1533-05 LED (PG) E3
D61-65
✽
B30-1729-05 LED (BLUE)
EE1E2
D61-65
✽
B30-1729-05 LED (BLUE)
E6E7E8
D61-65
✽
B30-1729-05 LED (BLUE) E9
D70 B30-1567-05 LED (RED)
C10 CK73GB0J225K CHIP C 2.2UF K
C11,12 CK73GB1H103K CHIP C 0.010UF K
C15 CC73GCH1H470J CHIP C 47PF J
C21 CK73FB1A225K CHIP C 2.2UF K EE7
C61-65 CK73GB1H103K CHIP C 0.010UF K
EE1E2
C61-65 CK73GB1H103K CHIP C 0.010UF K
E6E7E8
C61-65 CK73GB1H103K CHIP C 0.010UF K E9
J1
✽
E59-0840-05 RECTANGULAR PLUG
CP11 RK74HB1J103J CHIP-COM 10K J 1/16W
R1,2 RK73GB2A222J CHIP R 2.2K J 1/10W
EE1E2
R1,2 RK73GB2A222J CHIP R 2.2K J 1/10W
E7E8E9
R11 RK73GB2A471J CHIP R 470 J 1/10W
R13 RK73GB2A471J CHIP R 470 J 1/10W
R14 RK73GB2A221J CHIP R 220 J 1/10W
R15-17 RK73GB2A471J CHIP R 470 J 1/10W
R18 RK73GB2A102J CHIP R 1.0K J 1/10W
R19 RK73GB2A471J CHIP R 470 J 1/10W
R21 RK73GB2A104J CHIP R 100K J 1/10W EE7
R22 RK73GB2A101J CHIP R 100 J 1/10W EE7
R23 RK73GB2A104J CHIP R 100K J 1/10W
E1E2E3
R23 RK73GB2A104J CHIP R 100K J 1/10W
E6E8E9
R31-34 RK73FB2B471J CHIP R 470 J 1/8W
R61 RK73EB2E621J CHIP R 620 J 1/4W E3
R61,62 RK73EB2E301J CHIP R 300 J 1/4W
EE1E2
R61,62 RK73EB2E301J CHIP R 300 J 1/4W
E6E7E8
R61,62 RK73EB2E301J CHIP R 300 J 1/4W E9
R62,63 RK73EB2E561J CHIP R 560 J 1/4W E3
R63 RK73EB2E471J CHIP R 470 J 1/4W
EE1E2
R63 RK73EB2E471J CHIP R 470 J 1/4W
E6E7E8
R63 RK73EB2E471J CHIP R 470 J 1/4W E9
R70 RK73GB2A221J CHIP R 220 J 1/10W
R72 RK73GB2A472J CHIP R 4.7K J 1/10W
R74 RK73GB2A4R7J CHIP R 4.7 J 1/10W
R75 RK73GB2A203J CHIP R 20K J 1/10W
R78 RK73GB2A102J CHIP R 1.0K J 1/10W
R80
✽
RK73SB3A330J CHIP R 33 J 1W
R82
✽
RK73SB3A330J CHIP R 33 J 1W
W1 R92-1252-05 CHIP R 0 OHM J 1/16W E3
W2 R92-1252-05 CHIP R 0 OHM J 1/16W E6
W11 R92-1252-05 CHIP R 0 OHM J 1/16W
W14 R92-1252-05 CHIP R 0 OHM J 1/16W
S12 S70-0106-05 TACT SWITCH
S11
✽
T99-0457-05 ROTARY ENCODER
D71-77 UDZS5.6B ZENER DIODE
D71-77
✽
02DZ5.6F-Y ZENER DIODE
D96 DA204U DIODE EE7
ED1
✽
3-BT-224N
FLUORESCENT INDICATOR TUBE
IC1
✽
LC75756W MOS-IC
IC3 PNA4S22M ANALOGUE IC EE7
Q1,2
✽
KTC4075EP(Y,GR) TRANSISTOR
EE1E2
Q1,2
✽
KTC4075EP(Y,GR) TRANSISTOR
E7E8E9
Q1,2 2SC4617 TRANSISTOR
EE1E2
Q1,2 2SC4617 TRANSISTOR
E7E8E9
Q1,2
✽
2SC5383(E,F) TRANSISTOR
EE1E2
Q1,2
✽
2SC5383(E,F) TRANSISTOR
E7E8E9
Q21 DTA114EE DIGITAL TRANSISTOR
Q21
✽
KRA302E-P DIGITAL TRANSISTOR
Q21 RT1P141U TRANSISTOR
C1,2 CK73GB1H222K CHIP C 2200PF K
C3,4 CK73GB0J105K CHIP C 1.0UF K
C5 CK73GB1C104K CHIP C 0.10UF K
C6 CK73GB1H103K CHIP C 0.010UF K
C7-9 CK73GB0J105K CHIP C 1.0UF K
C10-15 CK73GB1C104K CHIP C 0.10UF K
C16 CK73FB0J475K CHIP C 4.7UF K
C17 CK73FB0J106M CHIP C 10UF M
C18 CK73GB1C104K CHIP C 0.10UF K
C19 CK73FB0J475K CHIP C 4.7UF K
C20 CK73GB1C104K CHIP C 0.10UF K
C21 CK73GB1H102K CHIP C 1000PF K
C22,23 CK73GB0J105K CHIP C 1.0UF K
C24-27 CK73GB1C104K CHIP C 0.10UF K
C28 CK73FB0J106M CHIP C 10UF M
C29 CK73GB1C104K CHIP C 0.10UF K
C30 CK73GB1H152K CHIP C 1500PF K
C31 CC73GCH1H470J CHIP C 47PF J
C32,33 CK73GB1C104K CHIP C 0.10UF K
C34 CC73GCH1H560J CHIP C 56PF J
C35,36 CK73GB1C104K CHIP C 0.10UF K
C37 CK73GB1H102K CHIP C 1000PF K
C38 CK73GB1H682K CHIP C 6800PF K
C39 CK73GB1C104K CHIP C 0.10UF K
C41 CK73GB1A334K CHIP C 0.33UF K
C42-45 CK73GB1C104K CHIP C 0.10UF K
C46 CK73GB1H682K CHIP C 6800PF K
C47 CK73GB1C104K CHIP C 0.10UF K
C48 CC73GCH1H040C CHIP C 4.0PF C
C49 CK73GB1H332K CHIP C 3300PF K
C50 CK73GB1C104K CHIP C 0.10UF K
C51 CC73GCH1H330J CHIP C 33PF J
C52 CK73FB1A225K CHIP C 2.2UF K
C53 CK73GB0J105K CHIP C 1.0UF K
C54,55 CK73GB1H103K CHIP C 0.010UF K
C56,57 CK73GB1H331K CHIP C 330PF K
C58 CK73GB1H472K CHIP C 4700PF K
C59,60 CK73GB1H152K CHIP C 1500PF K
C61,62 CK73GB1H102K CHIP C 1000PF K
