30
KDC-W4031/W4031Y/W409/W409Y
KDC-W431GY/W4531/W4531Y/WF431A
Indicates safety critical components.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
PARTS LIST
E : KDC-W4531 E1 : KDC-W4031 E2 : KDC-W409 E3 : KDC-W431GY E6 : KDC-WF431A
E7 : KDC-W4531Y E8 : KDC-W4031Y E9 : KDC-W409Y
(E : Europe K : North America M : Other Areas W : Without Europe)
C63 CK73GB1H152K CHIP C 1500PF K
C64 CK73GB1C104K CHIP C 0.10UF K
C66 CC73GCH1H120J CHIP C 12PF J
C67 CC73GCH1H180J CHIP C 18PF J
C68 CK73GB1H103K CHIP C 0.010UF K
C69 CK73FB1A225K CHIP C 2.2UF K
C70 CK73FB1A105K CHIP C 1.0UF K
C71 CK73FB0J106M CHIP C 10UF M
C72 CK73GB1H102K CHIP C 1000PF K
CN1 E41-2083-05 FLAT CABLE CONNECTOR
CN2 E41-2068-05 FLAT CABLE CONNECTOR
CN2 E41-2085-15 FLAT CABLE CONNECTOR
L1,2 L92-0386-05 CHIP FERRITE
X1 L77-2808-05
CRYSTAL RESONATOR (16.897849MHZ)
X2 L78-0896-05 RESONATOR (16.00MHZ)
CP1 RK74GA1J104J CHIP-COM 100K J 1/16W
CP2,3 RK74GA1J101J CHIP-COM 100 J 1/16W
CP4 RK74GA1J103J CHIP-COM 10K J 1/16W
CP5 RK74GA1J102J CHIP-COM 1.0K J 1/16W
CP6 RK74GA1J104J CHIP-COM 100K J 1/16W
CP7 RK74GB1J102J CHIP-COM 1.0K J 1/16W
CP8 RK74GA1J102J CHIP-COM 1.0K J 1/16W
CP9 RK74GB1J101J CHIP-COM 100 J 1/16W
CP10 RK74GB1J103J CHIP-COM 10K J 1/16W
CP11 RK74GB1J472J CHIP-COM 4.7K J 1/16W
CP12 RK74GA1J104J CHIP-COM 100K J 1/16W
CP13,14 RK74GB1J104J CHIP-COM 100K J 1/16W
CP15 RK74GA1J104J CHIP-COM 100K J 1/16W
CP16 RK74GB1J222J CHIP-COM 2.2K J 1/16W
R1 RK73GB2A100J CHIP R 10 J 1/10W
R2 R92-3494-05 CHIP R 5.6 F 1/2W
R3,4 RK73FB2B331J CHIP R 330 J 1/8W
R5 RK73GB2A101J CHIP R 100 J 1/10W
R6 RN73GH1J223D CHIP R 22K D 1/16W
R7 RK73GB2A104J CHIP R 100K J 1/10W
R8 RN73GH1J393D CHIP R 39K D 1/16W
R9 RK73GB2A104J CHIP R 100K J 1/10W
R10 RK73GB2A101J CHIP R 100 J 1/10W
R11,12 RK73GB2A104J CHIP R 100K J 1/10W
R13 RK73GB2A102J CHIP R 1.0K J 1/10W
R14-17 RK73GB2A104J CHIP R 100K J 1/10W
R18 RK73GB2A101J CHIP R 100 J 1/10W
R21-23 RK73GB2A103J CHIP R 10K J 1/10W
R24,25 RK73GB2A4R7J CHIP R 4.7 J 1/10W
R27 RK73GB2A104J CHIP R 100K J 1/10W
R28 RK73GB2A103J CHIP R 10K J 1/10W
R29 RK73GB2A102J CHIP R 1.0K J 1/10W
R31-33 RK73GB2A104J CHIP R 100K J 1/10W
R34 RK73GB2A472J CHIP R 4.7K J 1/10W
R35 RK73GB2A104J CHIP R 100K J 1/10W
R36 RK73FB2B4R7J CHIP R 4.7 J 1/8W
R37 RK73GB2A103J CHIP R 10K J 1/10W
R38 RK73GB2A221J CHIP R 220 J 1/10W
R39 RK73GB2A152J CHIP R 1.5K J 1/10W
R40 RK73GB2A394J CHIP R 390K J 1/10W
R42 RK73GB2A101J CHIP R 100 J 1/10W
R43 RK73GB2A393J CHIP R 39K J 1/10W
R44,45 RK73GB2A302J CHIP R 3.0K J 1/10W
R46 RK73GB2A105J CHIP R 1.0M J 1/10W
R47 RK73GB2A104J CHIP R 100K J 1/10W
R48,49 RK73GB2A331J CHIP R 330 J 1/10W
R50 RK73GB2A101J CHIP R 100 J 1/10W
R51 RK73GB2A392J CHIP R 3.9K J 1/10W
R52 RK73GB2A163J CHIP R 16K J 1/10W
R53 RK73GB2A123J CHIP R 12K J 1/10W
R54 RK73GB2A333J CHIP R 33K J 1/10W
R55 RK73GB2A103J CHIP R 10K J 1/10W
R56 RK73GB2A123J CHIP R 12K J 1/10W
R57,58 RK73GB2A133J CHIP R 13K J 1/10W
R59 RK73GB2A472J CHIP R 4.7K J 1/10W
R60 RK73GB2A123J CHIP R 12K J 1/10W
R61 RK73GB2A183J CHIP R 18K J 1/10W
R62 RK73GB2A432J CHIP R 4.3K J 1/10W
R63 RK73GB2A133J CHIP R 13K J 1/10W
R64 RK73GB2A151J CHIP R 150 J 1/10W
R65 RK73GB2A104J CHIP R 100K J 1/10W
R66 RK73GB2A472J CHIP R 4.7K J 1/10W
R67 RK73GB2A222J CHIP R 2.2K J 1/10W
R68,69 RK73GB2A104J CHIP R 100K J 1/10W
R70 RK73GB2A102J CHIP R 1.0K J 1/10W
S1,2 S68-0863-05 PUSH SWITCH
S3 S68-0862-05 PUSH SWITCH
D2 DA204UF DIODE
D3 DAN202UF DIODE
IC1 91CW12AFG-5AR1 MICROCONTROLLER IC
IC2 UPD63712GC MOS-IC
IC3 TC94A20F-010 MOS-IC
IC4 BA5824FP-F ANALOGUE IC
IC5 NJM2880U133 ANALOGUE IC
IC5 NJM2880U33 ANALOGUE IC
IC6 S-1112B33MCG ANALOGUE IC
IC6 XC6219B332MR ANALOGUE IC
IC7 S-1112B25MCG ANALOGUE IC
IC7 XC6219B252MR ANALOGUE IC
IC8 TC7SH08FU MOS-IC
IC9 TAR5S33-F ANALOGUE IC
Q1 2SK3018F FET
Q3 UMD9N TRANSISTOR
Q4 2SK3018F FET
Q5 UMD9N TRANSISTOR
Q6 UMD12N TRANSISTOR
Q7 DTC124EUAF DIGITAL TRANSISTOR
Q8 2SB0970 TRANSISTOR
Q9,10 DTC114YUAF DIGITAL TRANSISTOR
D401 B30-1567-05 LED (RED)
ELECTRIC UNIT (X34-3402-7x)
CD PLAYER UNIT (X32-5500-00)
