3
KDC-W4031/W4031Y/W409/W409Y
KDC-W431GY/W4531/W4531Y/WF431A
COMPONENTS DESCRIPTION
● ELECTRIC UNIT (X34-3402-7x)
Ref. No. Application / Function Operation / Condition
IC1 SYSTEM µ-COM System control.
IC3 POWER SUPPLY DC5Vx2, 7.9Vx1, 8.1Vx1, 10.3V, P.CON, P-ANT output.
IC4 POWER IC Audio signal amplifier.
IC6 MUTE LOGIC Mute control.
IC7 RDS DECODER RDS decode.
IC8 RESET “L” when detection voltage goes below 3.6V.
IC10 E-VOL & TUNER E-VOL, Tuner, Stereo decode.
IC11 E2PROM Saves and writes tuner adjustment data.
IC15 VFD REGULATOR 11.3V output voltage for LED and VFD.
Q51 SERGE DET “ON” when the base goes “H”.
Q52 BU DET “ON” when the base goes “H”.
Q53 ACC DET “ON” when the base goes “H”.
Q71 SERVO+B CONTROL SW “ON” when the base goes “H”.
Q72,73 SERVO+B AVR Output voltage level : 7.5V.
Q74 IC3 CONTROL SW “ON” when the base goes “H” (Output voltage : 10.3V).
Q151 PANEL 5V SW “ON” when the base goes “L”.
Q155 DSI ILLUMI SW “ON” when the base goes “L”.
Q252 IC4 STBY SW “ON” when the base goes “L”.
Q330 Q351, 352 MUTE DRIVER “ON” when the base goes “L”.
Q351 Lch PRE MUTE SW Pre-output is muted when the base goes “H”.
Q352 Rch PRE MUTE SW Pre-output is muted when the base goes “H”.
Q501 AM RF AMP Adjusts for AM-RF gain.
● CD PLAYER UNIT (X32-5500-00)
Ref. No. Application / Function Operation / Condition
Focusing, tracking, sled and spindle servo processing.
IC1
MECHANISM CONTROL Automatic adjustment (Focusing, tracking, gain, offset and balance) operations.
MICROPROCESSOR Digital signal processing (DSP, PLL, sub-codes, CIRC error correction, audio data
interpolation) operations, and microcomputer function.
Generation of RF signal based on the signals from the APC circuit and pickup, and
IC2
RF AMP/SERVO CD generation of servo error (Focusing error and tracking error) signals.
SIGNAL PROCESSOR Detection of dropout, anti-shock, track crossing and off-track conditions, included
gain control function during CD-RW.
IC3 MP3/WMA DECODER
IC4 4ch BTL DRIVER
Focusing coil, tracking coil, spindle motor and sled motor driver, disc loading and
eject operation.
IC5 SW 3.3V AVR
IC6 BU 3.3V AVR 3.3V power supply for back-up.
IC7 BU 2.5V AVR 2.5V power supply for back-up.
