Kenwood KDC-W4031 [32/38] Parts list
![Kenwood KDC-WF431A [32/38] Parts list](/views2/1263108/page32/bg20.png)
32
KDC-W4031/W4031Y/W409/W409Y
KDC-W431GY/W4531/W4531Y/WF431A
Indicates safety critical components.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
PARTS LIST
E : KDC-W4531 E1 : KDC-W4031 E2 : KDC-W409 E3 : KDC-W431GY E6 : KDC-WF431A
E7 : KDC-W4531Y E8 : KDC-W4031Y E9 : KDC-W409Y
(E : Europe K : North America M : Other Areas W : Without Europe)
C601 CK73GB1H223K CHIP C 0.022UF K
C602 CC73GCH1H151J CHIP C 150PF J
C604 CC73GCH1H470J CHIP C 47PF J
C605,606 CC73GCH1H010C CHIP C 1.0PF C
C610 CC73GCH1H010C CHIP C 1.0PF C
C620 CK73GB1H103K CHIP C 0.010UF K
C623,624 CK73GB1H103K CHIP C 0.010UF K
C625,626 CC73GCH1H101J CHIP C 100PF J
CN2
✽
E41-2244-05 FLAT CABLE CONNECTOR
CN3 E41-0941-05 PIN ASSY
EE1E2
CN3 E41-0941-05 PIN ASSY
E6E7E8
CN3 E41-0941-05 PIN ASSY E9
J1 E58-0991-05 RECTANGULAR RECEPTACLE
J2 E56-0855-05 CYLINDRICAL RECEPTACLE EE7
J4 E04-0326-05
RF COAXIAL CABLE RECEPTACLE
J5
✽
E58-0992-05 RECTANGULAR RECEPTACLE
J6 E63-0898-05 PIN JACK
P1 E23-0745-05 TERMINAL
W251 E31-0001-00 JUMPER WIRE E3E6
W300-302 E31-0001-00 JUMPER WIRE E3
W300-311 E31-0001-00 JUMPER WIRE
E1E2E6
W300-311 E31-0001-00 JUMPER WIRE E8E9
W300-324 E31-0001-00 JUMPER WIRE EE7
W304-311 E31-0001-00 JUMPER WIRE E3
W313-324 E31-0001-00 JUMPER WIRE
E1E2E3
W313-324 E31-0001-00 JUMPER WIRE
E6E8E9
W326-329 E31-0001-00 JUMPER WIRE E3
W326-337 E31-0001-00 JUMPER WIRE
E1E2E6
W326-337 E31-0001-00 JUMPER WIRE E8E9
W326-345 E31-0001-00 JUMPER WIRE EE7
W331-337 E31-0001-00 JUMPER WIRE E3
W339-341 E31-0001-00 JUMPER WIRE
E1E2E3
W339-341 E31-0001-00 JUMPER WIRE
E6E8E9
W345 E31-0001-00 JUMPER WIRE
E1E2E8
W345 E31-0001-00 JUMPER WIRE E9
W345-347 E31-0001-00 JUMPER WIRE E6
W346,347 E31-0001-00 JUMPER WIRE E3
W347 E31-0001-00 JUMPER WIRE
E1E2E8
W347 E31-0001-00 JUMPER WIRE E9
W347-366 E31-0001-00 JUMPER WIRE EE7
W349-353 E31-0001-00 JUMPER WIRE
E1E2E3
W349-353 E31-0001-00 JUMPER WIRE
E6E8E9
W355-357 E31-0001-00 JUMPER WIRE
E1E2E3
W355-357 E31-0001-00 JUMPER WIRE
E6E8E9
W361-366 E31-0001-00 JUMPER WIRE
E1E2E3
W361-366 E31-0001-00 JUMPER WIRE
E6E8E9
W368-372 E31-0001-00 JUMPER WIRE E3
W368-399 E31-0001-00 JUMPER WIRE E6
W369-376 E31-0001-00 JUMPER WIRE
EE1E2
W369-376 E31-0001-00 JUMPER WIRE
E7E8E9
W374-393 E31-0001-00 JUMPER WIRE E3
W378-399 E31-0001-00 JUMPER WIRE
EE1E2
W378-399 E31-0001-00 JUMPER WIRE
E7E8E9
W395-399 E31-0001-00 JUMPER WIRE E3
W401-410 E31-0001-00 JUMPER WIRE
W412-427 E31-0001-00 JUMPER WIRE
W801 E31-0001-00 JUMPER WIRE
W830 E31-0001-00 JUMPER WIRE
CF51-53
✽
L72-0805-05 CERAMIC FILTER (10.7MHZ)
CF54
✽
L72-0804-05 CERAMIC FILTER (450KHZ)
L3 L33-1978-05 CHOKE COIL (22UH)
L4
✽
L33-2260-05 CHOKE COIL (52UH)
L51 L33-1988-05 CHOKE COIL ASSY (140UH)
L61 L40-4795-91
SMALL FIXED INDUCTOR (4.7UH, J)
L101 L40-4795-91
SMALL FIXED INDUCTOR (4.7UH, J)
EE1E2
L101 L40-4795-91
SMALL FIXED INDUCTOR (4.7UH, J)
E6E7E8
L101 L40-4795-91
SMALL FIXED INDUCTOR (4.7UH, J)
E9
L501 L40-6891-58
SMALL FIXED INDUCTOR (6.8UH)
L502 L40-3301-58
SMALL FIXED INDUCTOR (33UH)
L503 L40-1021-56
SMALL FIXED INDUCTOR (1UH)
L504 L40-1011-58
SMALL FIXED INDUCTOR (100UH)
L505
✽
L40-3381-58
SMALL FIXED INDUCTOR (0.33UH)
L506
✽
L31-0977-15 FM-RF COIL
L507
✽
L32-0941-15 FM OSCILLATING COIL
L508
✽
L30-0776-15 FM IFT
L509
✽
L30-0777-15 AM IFT
L518
✽
L31-0976-15 FM-RF COIL
L519
✽
L40-4763-72
SMALL FIXED INDUCTOR (4.7NH)
L520
✽
L40-3381-58
SMALL FIXED INDUCTOR (0.33UH)
L521
✽
L40-1073-72
SMALL FIXED INDUCTOR (10NH)
L600
✽
L92-0607-05 CHIP FERRITE
L601,602 L92-0397-05 CHIP FERRITE
X1 L78-0879-05 RESONATOR (10.000MHZ)
X2 L77-2793-05
CRYSTAL RESONATOR (32.768KHZ)
X3 L77-2002-05
CRYSTAL RESONATOR (4.332MHZ)
EE1E2
X3 L77-2002-05
CRYSTAL RESONATOR (4.332MHZ)
E6E7E8
X3 L77-2002-05
CRYSTAL RESONATOR (4.332MHZ)
E9
X501 L77-2077-05
CRYSTAL RESONATOR (10.250MHZ)
F2D
✽
N80-3010-48 PAN HEAD TAPTITE SCREW
G2D
✽
N83-3005-48 PAN HEAD TAPTITE SCREW
H2D
✽
N83-3020-48 PAN HEAD TAPTITE SCREW
J3DN86-2606-48
BINDING HEAD TAPTITE SCREW
R1,2 RK73GB2A101J CHIP R 100 J 1/10W
R21 RD14BB2C152J RD 1.5K J 1/6W
R51 RK73FB2B683J CHIP R 68K J 1/8W
R52 RK73GB2A393J CHIP R 39K J 1/10W
R53 RK73GB2A104J CHIP R 100K J 1/10W
R54 RK73FB2B203J CHIP R 20K J 1/8W
R55,56 RK73GB2A103J CHIP R 10K J 1/10W
R57 RK73GB2A223J CHIP R 22K J 1/10W
R58 RD14DB2H332J SMALL-RD 3.3K J 1/2W
R59 RD14BB2C333J RD 33K J 1/6W
R60 RK73GB2A103J CHIP R 10K J 1/10W
R61 RK73GB2A223J CHIP R 22K J 1/10W
R72,73 RD14BB2C472J RD 4.7K J 1/6W
R75-78 RK73GB2A103J CHIP R 10K J 1/10W
R81 RD14BB2C103J RD 10K J 1/6W
R82 RK73GB2A223J CHIP R 22K J 1/10W
ELECTRIC UNIT (X34-3402-7x)
