English
Avoid overheating your electric tool, when using it for Lock keyless chuck 1 or 12 on the power tool spindle,
a long time.
having tightened screw 33. Attention: screw 33 has a
left-hand thread. Prior to that, move the cams of
keyless chuck 1 or 12 apart at the distance allowing
Mounting and adjustment of the
screw 33 to be tightened. To do that, rotate the front part
impact electric drill components
of keyless chuck 1 or 12 counter-clockwise with your
hand.
When keyless chuck 1 or 12 is being dismounted,
Before carrying out any works on the power tool it
repeat the aforementioned operations in reverse order.
must be disconnected from the mains.
Mounting / dismounting of the gear rim chuck
When implementing the mounting
operations, do not apply excessive force
during the tightening fastening of
[SBM-500 VS, SBM-600 VS, SBM-750 VS, SBM-810 VS,
SBM-810 VT, SBM-1050 VS, SBM-1050 VT, BM-1050 DL,
components in order not to damage the
threaded connections.
SBM-1050 DT]
Auxiliary handle
Screw gear rim chuck 2 onto the power tool spindle
(see picture 4).
[SBM-500 VS, SBM-600 VS, SBM-750 VS, SBM-750 V,
Lock gear rim chuck 2 on the power tool spindle,
SBM-810 VS, SBM-810 V, SBM-810 VT, SBM-1050 VS,
having tightened screw 33. Attention: screw 33 has
SBM-1050 VT, BM-1050 DL, SBM-1050 DT]
left-a hand thread. Prior to that move apart the cams of
gear rim chuck 2 at the distance allowing to tighten
When operating your tool hold additional handle 4 - it
screw 33 to be tightened. To do that, release the grip of
improves the operation performance comfort and the
the cams with clamping wrench 14, then rotate the quill
electric tool control.
of gear rim chuck 2 counter-clockwise with your hand.
Additional handle 4 may be positioned as deemed
When gear rim chuck 2 is being dismounted, repeat
comfortable by the user.
the aforementioned operations in reverse order.
[SBM-500 VS, SBM-600 VS, SBM-750 VS, SBM-750 V,
Mounting / replacement of accessories
SBM-810 VS, SBM-810 V, SBM-810 VT, SBM-1050 VS,
SBM-1050 VT, SBM-1050 DT]
It is necessary to wear gloves when
extracting the drill from the chuck
Loose additional handle 4 as shown in fig. 1.
because the drill can become very hot due
Place additional handle 4 in desired position.
to long operation. Wearing gloves when
Tighten additional handle 4 as shown in fig. 1.
mounting / replacing wire brushes is also
recommended.
[BM-1050 DL]
[BM-400 VS]
Release additional handle 4 as shown on picture 2.
Extract cork 32 and screw additional handle 4 into the
This model is equipped with keyless chuck 1. This
threaded opening.
allows accessories to be mounted / replaced quickly and
Insert cork 32 into the freed threaded opening.
without a key.
Depth stop
Move the cams of keyless chuck 1 apart at the
distance allowing an accessory to be mounted /
[SBM-500 VS, SBM-600 VS, SBM-750 VS, SBM-750 V,
replaced. To do that, rotate the front part of keyless
SBM-810 VS, SBM-810 V, SBM-810 VT, SBM-1050 VS,
chuck 1 counter-clockwise with your hand (see picture 5).
SBM-1050 VT, SBM-1050 DT]
Mount / replace an accessory.
Use depth limiter 3 to set a required drilling depth (see fig. 3).
Rotate the front part of keyless chuck 1 clockwise with
Slacken clamp 5.
your hand to lock the accessory mounted. Do not allow
Move depth limiter 3 to set a required drilling depth.
the accessory to become distorted.
Tighten clamp 5.
[SBM-750 V, SBM-810 V]
Mounting / dismounting of the keyless chuck
These models are equipped with keyless chuck (with
12
[BM-400 VS, SBM-750 V, SBM-810 V]
lock) . This allows accessories to be mounted /
replaced quickly and without a key and provides more
Screw keyless chuck 1 or 12 onto the power tool
reliable locking of the accessory compared to an
ordinary keyless chuck.
spindle (see picture 4).
18
