Securing the Child

1) Make sure booster seat is properly positioned and installed on

vehicle seat as per the instructions on page 11.

2) Properly position child: sitting upright and all the way back in

the booster seat.

3) Raise the headrest to access upper belt guides. Feed the

diagonal portion of the seat belt through the upper belt guide

on the side opposite the seat belt buckle.

4) Fasten seat belt across child: Lap portion of seat belt should

rest within both lower belt guides. Diagonal shoulder portion

should route inside the lower belt guide closest to the buckle

and over child’s shoulder.

5) Adjust headrest (page 9) to proper height: Upper shoulder

guide should be slightly above (at least 1 cm) the child’s

shoulders.

6) Make sure seat belt is not twisted and lays at across child’s

lap, torso and shoulder.

7) Tighten the seat belt by pulling the diagonal shoulder belt portion in the direction of

the arrows.

8) Conrm seat belt buckle is in correct position (see below).
