Diono Cambria Red [13/16] Backless booster seat

PROPER BUCKLE POSITION

IMPORTANT: After booster seat is installed and seat belt is fastened

around child, it is important to conrm correct seat belt buckle position

to ensure secure installation. Correct seat belt buckle position: Buckle is

on the outside of lower belt guide.

Incorrect seat belt buckle position.

If buckle is being pulled across the lower belt

guide and into the seat, choose another

seating position within the vehicle.

Backless Booster Seat

While this booster seat is designed to oer advanced side-impact

protection with its backrest section attached, the seat bottom can

also be used alone as a backless booster.

1) Remove seat bottom from backrest section (see page 9).A

2) Make sure booster seat is correctly installed (page 11) and

properly positioned on vehicle seat.

3) Properly position child: sitting upright and all the way back in

the booster seat.

4) Fasten seat belt across child.

WARNING: If lap portion and diagonal portion of seat belt are not positioned

correctly, the booster seat is not properly installed:

• Diagonal portion of seat belt should lay over the shoulder and NOT touching the neck.

• Lap belt position should be forward and as low as possible over child’s pelvis

and contacting the upper thigh.
