Diono Cambria Red [14/16] Using the shoulder belt guide strap

5) Make sure seat belt is not twisted and lays at across child’s hips, torso and shoulder.

6) Tighten the seat belt by pulling the diagonal shoulder belt portion in the direction of

the arrows.

IMPORTANT: Lap belt position should be as far forward and as low as possible over child’s

pelvis and contacting upper thighs.

IMPORTANT: Diagonal seat belt portion should route inside the lower belt guide closest to the

buckle and over child’s shoulder. It should NOT be touching the neck.

NEVER position the shoulder belt loosely or under the child’s arm or behind their back.

WARNING: If the diagonal seat belt portion does not correctly ﬁt the child, then

the seat must be used with the shoulder belt guide strap or with the seatback

portion attached and properly adjusted to ﬁt the child.

Using the Shoulder Belt Guide Strap

Remove shoulder belt guide strap from storage area

underneath seat.

Position child correctly in seat as per the instructions

in the manual, making sure lap and shoulder belts are

positioned properly across child.

Attach the red shoulder belt guide strap onto the

diagonal shoulder belt.

Adjust strap to correct length, so that red guide is just

above shoulder.
