Zigmund & Shtain EN 122.921 S [10/48] Page 10

The dimensions and material of the cabinet in which the oven will be installed must be

correct and resistant to increases in temperature. In a correct installation, contact with

electrical or insulated parts must be prevented. Insulating parts need to be fitted in a way to

ensure that they cannot be removed by using any kind of tool. Installing the appliance in the

close vicinity of a refrigerator or a deep-freezer is not recommended. Otherwise, the

performance of the above-mentioned appliances will be negatively affected due to

emanating heat. After removing your oven from its packaging, be sure that the oven is not

harmed. In case, you suspect of any damage to the appliance, do not use it; immediately

contact Authorized Service.

3.3. WIRING AND SAFETY OF BUILT_IN OVEN

The instructions given below must be followed without fail during wiring :

The earthing cable must be connected via the screw with the earthing mark. Supply cable

connection must be as shown in Figure 6. If there is no earthed outlet conforming to

regulations in the installation environment, call the Authorized Service immediately.

The earthed outlet must be in close vicinity of the appliance. Never use an extension cord.

The supply cable should not contact the product’s hot surface.

In case of any damage to the supply cable, make sure to call the Authorized Service. The

cable must be replaced by the Authorized Service.

Wiring of the appliance must be performed by the Authorized Service. H05VV-F type

supply cable must be used.

Faulty wiring may damage the appliance. Such a damage will not be covered under the

warranty.

The appliance is designed to connect to 220-240V~ electricity is different than the value

given above, call the Authorized Service immediately.

The Manufacturer Firm declares that its bears no responsibility whatsoever for any

kind of damage and loss arising from not complying with safety norms!

Figure 6

BLUE

BROWN

YELLOW+GREEN
