15
Getting Started
Getting Started
Step 6
Setting the clock
You must set the time and date on the
VCR to use the timer recording features
properly.
The Auto Clock Set function works only
if a station in your area is broadcasting a
time signal. If the Auto Set Up function
did not set the clock correctly for your
local area, try another station for the
Auto Clock Set function.
Before you start…
• Turn on the VCR and the TV.
• Set the TV to the video channel.
Setting the clock manually
1 Press MENU, then push the joystick to >/
. to select SETTINGS and press the
joystick (OK).
2 Push the joystick to >/. to select CLOCK,
then press the joystick (OK).
3 Push the joystick to >/. to move the
cursor (”) to the clock row, then push the
joystick to /.
The day starts flashing.
Joystick
>/./?//
OK
MENU
OK
PLAY
• MENU
OK
PLAY
OK
PLAY
SETTINGS
OPTIONS
TUNER
SHOWVIEW
CLOCK
LANGUAGE
SELECT
SET
:
:
OK
CLOCK
19TH8
AUTO ADJUST
SELECT
SET
END
1.1. 9
[]OFF
:
:
:OK
0:00
CLOCK
19TH8
AUTO ADJUST
SELECT
SET
END
:
:
:
1.1. 9
[]OFF
OK
0:00
continued
