Getting Started4

Getting Started

Step 1

Unpacking

Check that you have received the following items with the VCR:

Checking your model name

The instructions in this manual are for the 2 models: SLV-E780EN and

E780EG. Check your model number by looking at the rear panel of

your VCR. The SLV-E780EN is the model used for illustration

purposes. Any difference in operation is clearly indicated in the text,

for example, “SLV-E780EG only.”

• Remote commander

• R6 (size AA) batteries

• Aerial cable
