MSI B350M MORTAR [15/88] Specifications
![MSI B350M MORTAR [15/88] Specifications](/views2/1300762/page15/bgf.png)
15
Specifications
Specifications
CPU
Supports AMD
®
RYZEN series processors and 7th Gen
A-series/ Athlon™ processors for Socket AM4
Chipset AMD
®
B350 Chipset
Memory
y
4x DDR4 memory slots, support up to 64GB
Supports DDR4 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/
3200(OC)+ Mhz *
y
Dual channel memory architecture
y
Supports non-ECC UDIMM memory
y
Supports ECC UDIMM memory (non-ECC mode)
* 7th Gen A-series/ Athlon ™ processors support a maximum of 2400 MHz.
Please refer www.msi.com for more information on compatible memory.
Expansion Slots
y 1x PCIe 3.0 x16 slot
RYZEN series processors support x16 mode
7th Gen A-series/ Athlon™ processors support x8 mode
y 1x PCIe 2.0 x16 slot (supports x4 mode)
y 2x PCIe 2.0 x1 slots*
* PCI_E2 slot will be unavailable when an expansion card has been installed in
the PCI_E3 slot.
Onboard Graphics
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz*
y 1x HDMI™ 1.4 port, supports a maximum resolution of
4096x2160@24Hz*
y 1x DisplayPort, supports a maximum resolution of
4096x2160@60Hz*
* Only support when using a 7th Gen A-series/ Athlon™ processor
Multi-GPU
Supports 2-Way AMD
®
CrossFire
™
Technology
y RYZEN series processors support x16/x4 mode
y 7th Gen A-series/ Athlon™ processors support x8/x4 mode
Storage
AMD
®
B350 Chipset
y 4x SATA 6Gb/s ports*
y 1x M.2 port (Key M)
M2_1 slot supports PCIe 3.0 x4 (RYZEN series processor)
or PCIe 3.0 x2 (7th Gen A-series/ Athlon™ processors)
and SATA 6Gb/s 2242/ 2260 /2280 storage devices
y Supports RAID 0, RAID 1, RAID 10
Continued on next page
