Makita JR105DZ [7/44] Assembly

7ENGLISH

NOTE: Use a dry cloth to wipe the dirt off the lens of

the lamp. Be careful not to scratch the lens of lamp, or

it may lower the illumination.

Adjusting the shoe

►Fig.5: 1.Hexwrench  2.Hexbolt 3.Loosen

Whenthebladelosesitscuttingefciencyinoneplace

along its cutting edge, reposition the shoe to utilize a

sharp,unusedportionofitscuttingedge.Thiswillhelp

tolengthenthelifeoftheblade.

Torepositiontheshoe,loosentheboltwithhexwrench.

Slide the shoe to the desired position and then tighten

theboltrmly.

ASSEMBLY

CAUTION: Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing the recipro/jig

saw blade

CAUTION: Always clean out all chips or foreign

matter adhering to the blade, blade clamp and/or

slider.Failuretodosomaycauseinsufcienttighten-

ingoftheblade,resultinginaseriousinjury.

For Model JR103D

►Fig.6: 1.Reciprosawblade 2.Bladeclampsleeve

Insertthereciprosawbladeintothebladeclampasfar

asitwillgo.Thebladeclampsleeverotatesandxes

thereciprosawblade.Makesurethatthereciprosaw

bladecannotbeextractedeventhoughyoutrytopull

it out.

CAUTION: If you do not insert the recipro saw

blade deep enough, the recipro saw blade may be

ejected unexpectedly during operation.Thiscan

beextremelydangerous.

NOTE:Youcannotusethejigsawbladewith

JR103D.

►Fig.7: 1.Reciprosawblade 2.Bladeclampsleeve

Toremovethereciprosawblade,rotatetheblade

clampsleeveinthedirectionofthearrowfully.Thereci-

prosawbladeisremovedandthebladeclampsleeveis

xedatthereleasedposition.

NOTE:Ifyouremovethereciprosawbladewithout

rotatingthebladeclampsleevefully,thesleeve

maynotbexed.Inthiscase,rotatetheblade

clampsleevefully,thenmakethesleevexedatthe

released position.

For Model JR105D

►Fig.8: 1. Hex wrench 2. Bolt 3. Loosen

4.Tighten

►Fig.9: 1.Reciprosawblade 2.Hexwrench 

3.Holeforreciprosawblade  4.Bladeclamp

Toinstalltherecipro/jigsawblade,loosentheboltby

hexwrench.Wheninstallingareciprosawblade,press

theboltwiththehexwrenchtoopentheslotduring

insertingtheblade.

►Fig.10: 1.Recipro/jigsawblade  2.Bladeclamp

3.Holeforreciprosawblade  4.Holeforjigsaw

blade

►Fig.11

Youcanusebothjigsawblades(Btype)andrecipro

sawbladesaccordingtoyourwork.Inserttherecipro/

jigsawbladestraightintothebladeclampandtighten

itbyhexwrench.Pulltherecipro/jigsawbladelightlyto

makesurethattherecipro/jigsawbladedoesnotfalloff

during operation.

Toremovetherecipro/jigsawblade,followtheinstalla-

tion procedure in reverse.

Hex wrench storage

►Fig.12: 1. Hex wrench 2. Protrusion

When not in use, store the hex wrench as shown in the

guretokeepitfrombeinglost.

OPERATION

CAUTION: Always press the shoe rmly

against the workpiece during operation. If the

shoe is held away from the workpiece during opera-

tion,strongvibrationand/ortwistingwillbeproduced,

causingthebladetosnapdangerously.

CAUTION: Always wear gloves to protect your

hands from hot ying chips when cutting metal.

CAUTION: Be sure to always wear suitable eye

protection which conforms with current national

standards.

CAUTION: Always use a suitable coolant (cut-

ting oil) when cutting metal. Failure to do so will

causeprematurebladewear.

►Fig.13

Presstheshoermlyagainsttheworkpiece.Donot

allowthetooltobounce.Bringthereciprosawblade

into light contact with the workpiece. First, make a pilot

grooveusingaslowerspeed.Thenuseafasterspeed

to continue cutting.

►Fig.14

►Fig.15

You can use the switch lever or trigger according to your

work.

NOTE: If the tool is operated continuously until the

batterycartridgehasdischarged,allowthetooltorest

for15minutesbeforeproceedingwithafreshbattery.
