4
ENGLISH (Original instructions)
Explanation of general view
1-1. Switch trigger
2-1. Lamp
3-1. Adjusting dial
4-1. Lock button
4-2. Pointer
4-3. Change lever
5-1. Lock button
5-2. Change lever
5-3. Pointer
6-1. Pointer
6-2. Change lever
6-3. Lock button
7-1. Power-ON indicator lamp (green)
7-2. Service indicator lamp (red)
8-1. Side grip
9-1. Bit shank
9-2. Bit grease
10-1. Bit
10-2. Chuck cover
11-1. Bit
11-2. Chuck cover
12-1. Change lever
12-2. Lock button
12-3. Pointer
13-1. Depth gauge
13-2. Clamp screw
15-1. Blow-out bulb
18-1. Screws
19-1. Connector
20-1. Crank cap cover
20-2. Screws
21-1. Screws
24-1. Connector
SPECIFICATIONS
Model HR3540C HR3541FC
Tungsten-carbide tipped bit 35 mm
Concrete
Core bit 90 mm
Steel 13 mm
Capacities
Wood 32 mm
No load speed (min
-1
) 315 - 630
Blows per minute 1,650 - 3,300
Overall length 439 mm
Net weight 5.2 kg 5.6 kg
Safety class /II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
ENE044-1
Intended use
The tool is intended for hammer drilling in brick, concrete
and stone as well as for chiselling work.
ENF002-1
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.
For Model HR3540C
ENG102-3
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA
) : 93 dB(A)
Sound power level (L
WA
) : 104 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG215-2
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Work mode : chiseling function
Vibration emission (a
h,CHeq
) : 12.5 m/s
2
Uncertainty (K) : 1.5 m/s
2
ENG303-2
Work mode : hammer drilling into concrete
Vibration emission (a
h,HD
) : 18.0 m/s
2
Uncertainty (K) : 1.5 m/s
2
ENG301-1
Work mode : drilling into metal
Vibration emission (a
h,D
) : 2.5 m/s
2
Uncertainty (K) : 1.5 m/s
2
For Model HR3541FC
ENG102-3
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA
) : 91 dB(A)
Sound power level (L
WA
) : 102 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
