LG WD-12200 ND [8/34] Connect drain hose
![LG WD-12200 ND [8/34] Connect drain hose](/views2/1301726/page8/bg8.png)
HOW TO CONNECT INLET HOSE
Check that the rubber washer is the inside of
valve connector.
Connect the inlet hose firmly to prevent leak.
CONNECT DRAIN HOSE
CONNECT POWER PLUG
8
Make sure that the hose is not twisted.
The drain hose should be placed under 100cm from the floor.
Connect the power plug to the wall outlet.
Avoid connecting several electric devices,
It may be the cause of a fire.
Avoid submerging the end of the hose.
