Yaesu FT-65R [15/52] Normal operation display
![Yaesu FT-65R [15/52] Normal operation display](/views2/1302310/page15/bgf.png)
Controls & Connections (LCD)
Normal operation display
1 2 3 4
Single Display Mode (Default) Dual Display Mode
1
1 S & PO Meter ..................... 22 3 Battery Indicator ................ 19
2 Operating Frequency ....... 21 4 VFO-A / VFO-B ………… 24
The Set Mode and Preference Mode display
Set Mode Preferred Operating Mode
5
6
5 Set Mode Menu .................
23 6
Preferred Operating Mode Menu ..
.............................................
24
13FT-65R/FT-65E Operating Manual
