Controls & Connections (Keypad)
Key
Primary Function
(PRESS Key)
Secondary Func
-
tion
(PRESS F + Key)
Third Function
(Press and Hold Key)
Frequency entry digit “1” ―
Recalls the “Weather”
broadcast
channel bank
Frequency entry digit “2” ―
Activates the ARTS
feature
Frequency entry digit “3” ― ―
Frequency entry digit “4” ― ―
Frequency entry digit “5” ― ―
Frequency entry digit “6” ― Key Lock feature
Frequency entry digit “7” ― ―
Frequency entry digit “8” ― ―
Frequency entry digit “9” ― ―
Frequency entry digit “0” ― ―*1
recall the stored or
assigned setting
HOME (Fixed
setting)
store or assign a
setting to the key
TX PWR (Fixed
setting)
SQL TYPE (Fixed
setting)
REV (Fixed setting)
Switches the frequency control
between the VFO and Memory
Systems
Activates the Priori-
ty function
Memory write mode
Switches the band control
between VHF, UHF and FM
RADIO Broadcast
PMS(Program Mem-
ory (Mode) Scan)
Program Scan Setting
*1 : When entering a frequency from the keypad, there is a short-cut for
frequencies ending in zero - after the last non-zero digit, press and hold
the [0/SET] key to enter all the zeros at once.
15FT-65R/FT-65E Operating Manual
