MikroTik RB450G [10/10] Serial null modem console cable with loopback
![MikroTik RB450G [10/10] Serial null modem console cable with loopback](/views2/1303368/page10/bga.png)
RouterBOARD 450/G Series User's Manual
Serial Null-modem (Console) Cable with Loopback
DB9f Function DB9f DB25f
1 + 4 + 6 CD + DTR + DSR N/C N/C
N/C CD + DTR + DSR 1 + 4 + 6 6 + 8 + 20
2 RxD 3 2
3 TxD 2 3
5 GND 5 7
7 + 8 RTS + CTS N/C N/C
N/C RTS + CTS 7 + 8 4 + 5
N/C – not connected.
10
