RouterBOARD 450/G Series User's Manual
RouterBOARD 450 RouterBOARD 450G
CPU AR7131 300MHz AR7161 680MHz
Memory 32MB DDR RAM 256MB DDR SDRAM onboard memory
Boot loader RouterBOOT
Data storage onboard NAND memory chip
onboard NAND memory chip, microSD
card slot (on reverse)
Ethernet
Five 10/100 Ethernet ports supporting
Auto-MDI/X
Five 10/100/1000 Mbit/s Gigabit
Ethernet ports supporting Auto-MDI/X
MiniPCI slot none
Serial port One DB9 RS232C asynchronous serial port
LEDs Power and User LED
Beeper Present
Power
Power over Ethernet: 14..28V DC (except power over datalines)
Power jack: 10..28V DC
Fan control none
Dimensions 90 mm x 115 mm (3.5 in x 4.5 in)
Weight 95 g
Temperature Operational: -45°C to +70°C
Humidity Operational: up to 70% relative humidity (non-condensing)
Power consumption 6.4W at maximum load
Hardware Guide
Memory and Storage Devices
Onboard Memory
The RB450G equipped with 256 DDR SDRAM onboard memory, RB450 has 32MB DDR SDRAM onboard
memory.
Onboard NAND Storage Device
The boards are equipped with one built in NAND nonvolatile memory chip.
Extension Slots
MiniPCI Slots
The board has no miniPCI slots or other expansion abilities
Input/Output Ports
LAN1 Port with PoE
This Fast Ethernet port is recognized as the first LAN interface. It is compatible with passive (non-standard)
Power over Ethernet. The board accepts voltage input from 10 to 28 V DC. It is suggested to use the higher
voltage for power over long cables because of better efficiency (less power is lost in the cable itself and
power supply is more efficient).
See Connector Index for pinout of the standard cable required for PoE. All cables made to EIA/TIA 568A/B
cable specifications will work correctly with PoE. Note that this port supports automatic cross/straight cable
correction (Auto MDI/X), so you can use either straight or cross-over cable for connecting to other network
devices.
4
