6
Thank you for choosing this GYS product; please read this instruction manual carefully before installing and using the
product, and keep in a safe place for future reference.
This product has been designed to carry out the following operations in a car body workshop:
Dent pulling; welding of nails, rivets, rings and pins; removal of bumps and dents; sheet stretching. It is not designed
for the assembly of metal parts. This device is delivered with an earth clamp, a gun (with cable), a consumables and
accessories box, and an H07RNF mains cable.
ELECTRICITY SUPPLY
- GYSPOT 39.02 / Pro 230 / 2600 / 2700 : single phase supply 230V 50Hz. 16A Circuit breaker curve D 16 A (aM type
or C curve for 2600).
- GYSPOT 39.04 / Pro 400: Two phase supply 400V 50Hz. Use of PH 1 (1), PH 2 (2) and EARTH (PE). (FIG I Page 2)
16A Circuit breaker curve D 16 A fuse aM type.
NB: If the product trips the circuit breaker, please check that the correct fuse and an adequate circuit
breaker are being used.
• These are A-class devices. They are designed to be used in an industrial or professional environment.
In a different environment, it can be difficult to ensure electromagnetic compatibility, due to
conducted disturbances as well as radiation.
• Warning: these materials do not comply with IEC 61000-3-12. If they are to be connected to a low-
voltage main supply, it is the responsibility of the user to ensure they can be connected. If necessary
consult the operator of your electrical distribution system
OPERATING AND SETTING (FIG III-PAGE 2)
A- Gyspot 39.02 / 39.04 / Pro 230 / Pro 400
Connect the machine to an approprate power supply
Connect the gun with its connector.
Nb: Pro 230 and Pro 400 has, in addition to the power connector, a connector to command the
torch trigger:
- Connect the latter if you wish to start by using the trigger.
- Disconnect it if you prefer use the generator with automatic start (see OPERATION
section).
Press the « on/off » key (⑥).
The indicators switch on for few seconds then the machine displays:
•
① Tool, n°1 by default, (star welding or dent pulling clamp).
• ② Power level, n°5 by default, (setting adapted for 0.8mm steel sheets).
To change the power level, press the + or – keys (
③). Keep the desired key pressed to scroll through the levels
automatically.
The available power levels allow the straightening of sheets of varying thickness (fig IV-
Ⓐ).
To change the tool used with the gun, press the tool selection key (④).
The tool indicator will blink for 5 seconds. During this time, it is possible to change the tool number by pressing
the + or - keys (
③).
Available Tools (fig IV-
Ⓑ
)
1
Straightening using the star hammer,
or dent pulling clamp.
5 Welding rivets for side rods
2 Crimped welding wire or rings for straightening 6 Welding rings for fixing vehicle body.
3
Impact reduction with specific copper tip
7
Welding studs for vehicle body and connecting beams
4 Carbon electrode for tempering
