9
ESDE EN FR NL IT RU
Parts Overview
1. Eyepiece/rubber eyecups
2. Zoom
3. Focus wheel, focus ring
4. Optical tube
5. Tripod adapter thread
6. Main tube clamp
7. Fastening screw
8. Sun shield
9. Tripod head with thread screw
10. Fixing screw for tripod head
11. Tripod legs
12. Axes for vertical and horizontal movement
13. Panhandle with locking function
14. Attached dust cap
15. Soft carry case with carrying strap
Scope of supply
Spotting scope
Table tripod
Nylon carry case
Cleaning cloth
Fastening the scope on the tripod
Take the scope out of the packaging and pull out the tripod
legs (11) as far as they can go. Place the tripod on an even,
stable base, like a table.
Your scope has a normed tripod adaptor thread (5), which
can be screwed onto the tripod adapter thread screw (9)
on the tripod. After attaching, tighten the xing screw (10)
beneath the tripod head.
Aligning the scope for viewing
Unlock the vertical and horizontal axes (12) by turning the
panning handle (13) anticlockwise.
Now you can move scope, attached to the tripod head, on
both axes (vertical and horizontal), for optimal positioning.
When you have reached the desired observing position, the
scope can be locked by turning the panning handle (13)
clockwise.
