English
X99 Taichi
4 5
•
1 x CPU Optional/Water Pump Fan Connector (4-pin)
* e CPU Optional/Water Pump Fan supports the water cooler
fan of maximum 1.5A (18W) fan power.
•
3 x Chassis Fan Connectors (4-pin)
* CHA_FAN1 and CHA_FAN2 can auto detect if 3-pin or 4-pin
fan is in use.
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
•
1 x Front Panel Audio Connector
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
•
1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
•
1 x Dr. Debug with LED
•
1 x BIOS Selection Switch
BIOS
Feature
•
2 x AMI UEFI Legal BIOS with multilingual GUI support
(1 x Main BIOS and 1 x Backup BIOS)
•
Supports Secure Backup UEFI Technology
•
ACPI 5.0 Compliant wake up events
•
SMBIOS 2.7 Support
•
CPU, DRAM, PCH 1.05V, PCH 1.5V, VPPM Voltage Multi-
adjustment
Hardware
Monitor
•
CPU/Chassis/ CPU Optional/Water Pump Fan temperature
sensing
•
CPU/Chassis/ CPU Optional/Water Pump Tachometer
•
CPU/Chassis/ CPU Optional/Water Pump Quiet Fan (Auto
adjust chassis fan speed by CPU temperature)
•
CPU/Chassis/ CPU Optional/Water Pump Fan multi-speed
control
•
Voltage monitoring: +12V, +5V, +3.3V, CPU Input Voltage,
CPU Internal Voltages
OS
•
Microso® Windows® 10 64-bit / 8.1 64-bit / 8 64-bit / 7 32-
bit / 7 64-bit
