22 23
English
Fatal1ty E3V5 Performance Gaming/OC Series
TPM Header
(17-pin TPMS1)
(see p.7, No. 20)
is connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
digital certicates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.
PCIe Power Connector
(4-pin PCIE _PWR1)
(see p.7, No. 23)
+12V DETECT
GND
Please connect a 4 pin molex
power cable to this connector
when more than three graphics
cards are installed.
1
GN D
SM B_DATA _ MAIN
LA D 2
LA D 1
GN D
S_ PWRDWN #
SE RIRQ #
GN
D
P C ICL K
P C IRST #
LA D 3
+3 V
LA D 0
+3VS B
GN D
FR AM E
SM B_CLK_ M AIN
