ASUS TUF B350M-PLUS GAMING
1-3
CPU_FAN
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
CHA_FAN
GND
CHA FAN PWR
CHA FAN IN
CHA FAN PWM
Donotforgettoconnectthefancablestothefan
connectors.Insufcientairowinsidethesystemmay
damage the motherboard components. These are not
jumpers!Donotplacejumpercapsonthefanconnectors!
TheCPU_FANconnectorsupportsaCPUfanof
maximum1A(12W)fanpower.
5. DDR4 DIMM slots
Install2GB,4GB,8GB,and16GBunbufferedECCandnon-ECCDDR4DIMMsinto
theseDIMMsockets.
Formoredetails,refertoSystem memory.
4. AMD AM4 CPU socket
ThismotherboardcomeswithaAMDAM4socketdesignedforAMDRyzen™/7th
GenerationA-series/Athlon™processors.
Formoredetails,refertoCentral Processing Unit (CPU).
6. AMD B350 SATA 6.0Gb/s ports (7-pin SATA6G_1~6)
TheseportsconnecttoSATA6.0Gb/sharddiskdrivesviaSATA
6.0Gb/ssignalcables.
GND
RSATA_TXP
RSATA_TXN
GND
RSATA_RXN
RSATA_RXP
GND
SATA6G
3. FAN RGB header (4-pin FAN_RGB_HEADER)
ThisheaderisforRGBLEDstripsofaCPU
fan.
TheFANRGBheadersupportsCPUfans
withmulti-colorLEDstrips(12V/G/R/B)
andwithamaximumpowerratingof1A
(12V).
Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyisswitched
offorthepowercordisdetachedfromthepowersupply.Failuretodosomaycausesevere
damagetothemotherboard,peripherals,orcomponents.
PIN 1
+12V
GREEN
RED
BLUE
FAN_RGB_HEADER
LED cable
Fan cable
