ASUS TUF B350M-PLUS GAMING
1-9
1.3 Central Processing Unit (CPU)
ThemotherboardcomeswithanAMDAM4socketdesignedforAMD
Ryzen™/7thGenerationA-series/Athlon™processors.
UnplugallpowercablesbeforeinstallingtheCPU.
TheAM4sockethasadifferentpinoutfromtheFM2+/FM2socket.Ensurethatyouusea
CPUdesignedfortheAM4socket.TheCPUtsinonlyonecorrectorientation.DONOT
forcetheCPUintothesockettopreventbendingthepinsanddamagingtheCPU!
Installing the CPU
ApplytheThermalInterfaceMaterialtotheCPUheatsinkandCPUbeforeyouinstallthe
heatsink and fan if necessary.
1
3
2
4
