ASUS B250M-C PRO

1-3

Intel

B250 Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1~6)

These connectors connect to Serial ATA 6.0 Gb/s hard disk drives via Serial ATA 6.0

Gb/s signal cables.

When using hot-plug and NCQ, set the SATA Mode Selection item in the BIOS to

[AHCI].

USB 3.0 connector (20-1 pin USB3_12)

Connect a USB 3.0 module to this connector for additional USB 3.0 front or rear

panel ports. This connector complies with USB 3.0 specications and provides faster

data transfer speeds of up to 5 Gbps, faster charging time for USB-chargeable

devices, optimized power efciency, and backward compatibility with USB 2.0.

TPM connector (14-1 pin TPM)

This connector supports a Trusted Platform Module (TPM) system, which can

securely store keys, digital certicates, passwords and data. A TPM system also

helps enhance network security, protects digital identities, and ensures platform

integrity.

Speaker connector (4-pin SPEAKER)

The 4-pin connector is for the chassis-mounted system warning speaker. The

speaker allows you to hear system warnings.

System panel connector (10-1 pin F_PANEL)

This connector supports several chassis-mounted functions.

Clear RTC RAM (2-pin CLRTC)

This header allows you to uncongure ME and clear the CMOS

RTC RAM data of the system setup information such as date, time,

and system passwords.

To erase the RTC RAM:

1. Turn OFF the computer and unplug the power cord.

2. Use a metal object such as a screwdriver to short the two

pins.

3. Plug the power cord and turn ON the computer.

4. Hold down the <Del> key during the boot process and enter

BIOS setup to re-enter data.

If the steps above do not help, remove the onboard battery and short the two pins again

to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery.

CLRTC

+3V_BAT

GND

PIN 1
