Asus B250M-C PRO [9/26] Product introduction
![Asus B250M-C PRO/CSM [9/26] Product introduction](/views2/1307915/page9/bg9.png)
ASUS B250M-C PRO
1-1
Product introduction
1
Motherboard overview
• Unplug the power cord from the wall socket before touching any component.
• Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
• Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
• Unplug the power cord before installing or removing the motherboard. Failure to do so
can cause you physical injury and damage to motherboard components.
Place this
side towards
the rear of the
chassis
B250M-C PRO
PCI
PCIEX1
SPEAKER
CHASSIS
CLRTC
F_PANEL
TPM
LPT
USB3_12
AAFP
MONO_OUT
ATX12V
EATXPWR
CPU_FAN
CHA_FAN1
CHA_FAN2
BATTERY
PCIEX16_1
PCIEX16_2
Super
I/O
ASM
1083
ALC
887
WG
I219V
RTD
2168
DIGI
+VRM
24.4cm(9.6in)
23.1cm(9.1in)
LGA1151
Intel
®
B250
DDR4 DIMM_A1 (64bit, 288-pin module)
228022110 2260 2242
M.2(SOCKET3)
PCIE SATA IRST
X4 VX
DDR4 DIMM_A2 (64bit,288-pin module)
DDR4 DIMM_B1 (64bit, 288-pin module)
DDR4 DIMM_B2 (64bit, 288-pin module)
AUDIO
KBMS
DP12
LAN_USB78
USB3_34
USB3_56
64Mb
BIOS
SATA6G_4 SATA6G_3
SATA6G_6 SATA6G_5
SATA6G_2 SATA6G_1
USB1112USB910
COM1 COM2
DVI
1 432 51
1
10112 11 9
2
7
8
14
18
6
6
6131516
19
17
17
20
Scan the QR code to get the detailed pin denitions.
