Asus PRIME B250M-D [13/26] Rear panel connectors

ASUS PRIME B250M-D

1-5

1. PS/2 Mouse/Keyboard combo port.ThisportconnectstoaPS/2mouseorPS/2

keyboard.

2. Video Graphics Adapter (VGA) port.This15-pinportisforaVGAmonitororother

VGA-compatibledevices.

3. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoa

LocalAreaNetwork(LAN)throughanetworkhub.

Rear panel connectors

2 3 4

Activity/Link LED Speed LED

Status Description Status Description

Off Nolink OFF 10Mbpsconnection

Orange Linked ORANGE 100Mbpsconnection

Orange(Blinking) Dataactivity GREEN 1Gbpsconnection

Orange(Blinking

thensteady)

Readytowakeup

fromS5mode

_ _

LAN port

Speed

LED

Activity Link

LED

LAN port LED indications

4. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother

audiosources.

5. Line Out port (lime).Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1

and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.

6. Microphone port (pink).Thisportconnectstoamicrophone.

Refertotheaudiocongurationtableforthefunctionoftheaudioportsin2.1,4.1,5.1,or

7.1-channelconguration.
