vi
PRIME B250M-D specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS PRIME B250M-D motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
1 x M.2 screw package
Documentation
1 x User Manual
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for 7th / 6th Generation Intel
®
Core™ i7 / i5 / i3, Pentium
®
,
and Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
B250 Chipset
Memory
2 x DIMMs, max 32 GB, DDR4 2400* / 2133** MHz, non-ECC, un-buffered memory***
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Due to Intel
®
chipset limitation, DDR4 2400MHz memory frequency is only supported by 7th
Generation Intel
®
processors. Higher memory modules will run at the maximum transfer
rate of DDR4 2400MHz.
** Due to Intel
®
chipset limitation, DDR4 2133MHz and higher memory modules on 6th
Generation Intel
®
processors will run at the maximum transfer rate of DDR4 2133MHz.
*** Refer to www.asus.com for the Memory QVL (Qualied Vendors List).
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (@ x16 mode)
2 x PCI Express 3.0/2.0 x1 slots
1 x PCI slot
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI / D-sub ports
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160 @24Hz / 2560 x
1600 @60Hz
- Supports D-sub with maximum resolution of 1920 x 1200 @60Hz
Supports Intel
®
InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
Maximum shared memory of 1024 MB (for iGPU exclusively)
Storage
Intel
®
B250 Chipset:
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support
(SATA mode & x4 PCIE mode)*
- 6 x SATA 6.0 Gb/s ports (gray)
* When a device in SATA mode is installed on the M.2 socket, SATA port 1 is disabled.
LAN
Realtek
®
8111H Gigabit LAN supports LANGuard
