ASUS PRIME B250M-D
1-1
Product introduction
1
Motherboard overview
• Unplugthepowercordfromthewallsocketbeforetouchinganycomponent.
• Beforehandlingcomponents,useagroundedwriststraportouchasafelygrounded
objectorametalobject,suchasthepowersupplycase,toavoiddamagingthemdue
tostaticelectricity.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyis
switchedofforthepowercordisdetachedfromthepowersupply.Failuretodoso
maycauseseveredamagetothemotherboard,peripherals,orcomponents.
• Unplugthepowercordbeforeinstallingorremovingthemotherboard.Failuretodoso
cancauseyouphysicalinjuryanddamagetomotherboardcomponents.
Place this
side towards
the rear of the
chassis
PRIME B250M-D
PCIE SATA
M.2(SOCKET3)
IRST
X4 V X
PCIEX1_1
PCIEX16
PCIEX1_2
PCI
SPEAKER
CLRTC
F_PANEL
SPDIF_OUT
USB1112USB910
USB3_12
AAFP
ATX12V
EATXPWR
CPU_FAN
CHA_FAN
BATTERY
Super
I/O
ALC
887
ASM
1083
Realtek
8111H
DIGI
+VRM
24.4cm(9.6in)
LGA1151
Intel
®
B250
2280 2260 2242
M.2(SOCKET3)
DDR4 DIMM_A1 (64bit, 288-pin module)
DDR4 DIMM_B1 (64bit, 288-pin module)
AUDIO
KBMS_USB78
HDMI
LAN_USB3_34
USB3_56
18.3cm(7.2in)
64Mb
BIOS
SATA6G_6 SATA6G_5
SATA6G_3SATA6G_4 SATA6G_2 SATA6G_1
COM
VGA
LANGuard
32 21 4
1
8
7
6
1
5
11 1012
14
79
13
15
16
ScantheQRcodetogetthedetailedpindenitions.
