Chapter 1: Product introduction

Internal stereo speaker header (4-pin SPK_OUT)

The internal mono speaker header allows connection to an internal, low-power

speaker for basic system sound capability. The subsystem is capable of driving a

speaker load of 4 Ohms at 3 Watts (rms).

TPM connector (14-1 pin TPM)

This connector supports a Trusted Platform Module (TPM) system, which can

securely store keys, digital certicates, passwords and data. A TPM system also

helps enhance network security, protects digital identities, and ensures platform

integrity.

DMIC connector (5-1-pin DMIC)

The DMIC connector is for connecting the digital microphone module used in All-

in-One chassis.

Clear RTC RAM (2-pin CLRTC)

This header allows you to clear the CMOS RTC RAM data of

the system setup information such as date, time, and system

passwords.

To erase the RTC RAM:

1. Turn OFF the computer and unplug the power cord.

2. Use a metal object such as a screwdriver to short the two

pins.

3. Plug the power cord and turn ON the computer.

4. Hold down the <Del> key during the boot process and

enter BIOS setup to re-enter data.

If the steps above do not help, remove the onboard battery and short the

two pins again to clear the CMOS RTC RAM data. After clearing the CMOS,

reinstall the battery.

Front panel audio connector (10-1 pin AAFP)

This connector is for a chassis-mounted front panel audio I/O module that supports

HD Audio. Connect one end of the front panel audio I/O module cable to this

connector.

We recommend that you connect a high-denition front panel audio module to this

connector to avail of the motherboard’s high-denition audio capability

RTC Battery header (2-pin BATT_CON)

This connector is for the lithium CMOS battery.

CLRTC

+3V_BAT

GND

PIN 1
