ASUS H110T

1-5

When using PCI cards on shared slots, ensure that the drivers support “Share IRQ” or that

the cards do not need IRQ assignments. Otherwise, conicts will arise between the two PCI

groups, making the system unstable and the card inoperable.

IRQ assignments for this motherboard

A B C D E F G H

HD Audio Controller shared – – – – – – –

XHCI shared – – – – – – –

SATA Controller shared – – – – – – –

Realtek LAN Controller – shared – – – – – –

Intel Lan shared – – – – – – –

M.2 shared – – – – – – –

IGD shared – – – – – – –

WLAN shared – – – – – – –

M.2 WIFI

This socket connects to an M.2 WI-FI device. Use the bundled screw 3020-

01810100 to secure your M.2 device.

M.2 socket 3

This socket allows you to install an M.2 (NGFF) SSD module. Use the bundled

screw 13020-0181000 to secure your M.2 device.

This socket supports M Key and 2242/2260 storage devices.
