Asus H110T [8/28] Connectors for aio system
![Asus H110T [8/28] Connectors for aio system](/views2/1307925/page8/bg8.png)
viii
H110T specications summary
Specications
Internal
connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Front panel audio connector (AAFP)
1 x System Panel connector
1 x Clear CMOS jumper
1 x COM header
1 x TPM header
1 x Chassis intrusion connector
1 x SATA power connector
1 x Speaker connector
Connectors for AIO System
1 x 2-pin internal DC power connector
1 x Stereo speaker connector
1 x DMIC header
Connectors for Flat Panel Display
1 x Display panel backlight power selector
1 x Flat panel display brightness connector
1 x Display panel VCC power selector
1 x LCD panel monitor switch header
BIOS features
128 Mb Flash ROM, AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI
5.0, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, F12
PrintScreen, F6 Qfan Control
Manageability
WfM 2.0, DMI 3.0, WOL by PME
Support DVD
Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
OS support
Windows
®
10 *
Windows
®
8.1*
Windows
®
7
* 64-bit supported only
Form factor
Thin Mini-ITX Form Factor, 6.7 in x 6.7 in ( 17.0 cm x 17.0 cm )
Specications are subject to change without notice.
