ASUS H110T
1-7
6. Line Out port (lime). This port connects to a headphone or a speaker.
7. Microphone port (pink). This port connects to a microphone.
Activity/Link LED Speed LED
Status Description Status Description
Off No link OFF 10Mbps connection
Orange Linked ORANGE 100Mbps connection
Orange (Blinking) Data activity GREEN 1Gbps connection
Orange (Blinking
then steady)
Ready to wake up
from S5 mode
_ _
LAN port LED indications
Port
Headset
2.1-channel
4.1-channel 5.1-channel 7.1-channel
Line Ourt (Rear panel) Front Speaker Out Front Speaker Out Front Speaker Out Front Speaker Out
MIC(Rear panel) MIC Rear Speaker Out Rear Speaker Out Rear Speaker Out
Headphone (Front
panel)
Headphone Headphone
Center/Subwoofer
Speaker Out
Center/Subwoofer
Speaker Out
MIC (Front panel) MIC MIC MIC Side Speaker Out
Audio 2.1, 4.1, 5.1, or 7.1-channel conguration
