X11SSH-F/-LN4F User Manual

Motherboard Features

LED Indicators

• Power/suspend-state indicator LED

• UID/Remote UID LED

• Fan failed LED

• HDD activity LED

• CPU/system overheat LED

• LAN activiity LED

Other

• RoHS

Dimensions

• Micro ATX form factor (9.6" x 9.6") (243.84 mm x 243.84 mm)

Note 1: The CPU maximum thermal design power (TDP) is subject to chassis and

heatsink cooling restrictions. For proper thermal management, please check the chas-

sis and heatsink specications for proper CPU TDP sizing.

Note 2: For IPMI conguration instructions, please refer to the Embedded IPMI Con-

guration User's Guide available at http://www.supermicro.com/support/manuals/.
