Supermicro X11SSH-F-B [6/121] Chapter 3 troubleshooting
![Supermicro X11SSH-F-B [6/121] Chapter 3 troubleshooting](/views2/1308775/page6/bg6.png)
6
DIMM Removal .................................................................................................................34
2.5 Rear I/O Ports ....................................................................................................................35
2.6 Front Control Panel ............................................................................................................40
2.7 Connectors .........................................................................................................................45
Power Connections ...........................................................................................................45
Headers .............................................................................................................................47
2.8 Jumper Settings .................................................................................................................57
How Jumpers Work ...........................................................................................................57
2.9 LED Indicators ....................................................................................................................62
Chapter 3 Troubleshooting
3.1 Troubleshooting Procedures ..............................................................................................66
3.2 Technical Support Procedures ...........................................................................................70
3.3 Frequently Asked Questions ..............................................................................................71
3.4 Battery Removal and Installation .......................................................................................72
3.5 Returning Merchandise for Service ....................................................................................73
Chapter 4 BIOS
4.1 Introduction .........................................................................................................................74
4.2 Main Setup .........................................................................................................................75
4.3 Advanced Setup Congurations .........................................................................................77
4.4 Event Logs ......................................................................................................................... 99
4.5 IPMI ..................................................................................................................................100
4.6 Security .............................................................................................................................103
4.7 Boot Settings ....................................................................................................................105
4.8 Save & Exit .......................................................................................................................107
Appendix A BIOS Codes
Appendix B Software Installation
B.1 Installing Software Programs ...........................................................................................110
B.2 SuperDoctor
®
5 .................................................................................................................111
Appendix C Standardized Warning Statements
Battery Handling .............................................................................................................. 113
Product Disposal .............................................................................................................115
Appendix D UEFI BIOS Recovery
Appendix E Dual Boot Block
BIOS Boot Block .............................................................................................................120
BIOS Boot Block Corruption Occurrence ......................................................................120
X11SSH-F/-LN4F User Manual
