Chapter2:SettingUp

ConnectwithSynologyRS10613xs+

Connectoneendofthepowercord(s)tothepowerportofRX1213sasand

theothertothepoweroutlet(s).

Note:

YourRX1213sasaswellasRS10613xs+comesequippedwitharedundant

powersupplysystem,allowingtwopowercordstobeconnected.Thesystemmay

bepoweredonwithonlyonepowercord,butwerecommendusingtwopowercords

toavoidunexpectedpowerfailures.

ConnectoneendoftheSAScable(atleastone)totheSAS-INportof

RX1213sasandtheothertotheSAS-OUTportofRS10613xs+.

RS10613xs+

RX1213sas

Note:

IfyouwanttoconnectRX1213sastoanotherRX1213sas,connectoneend

oftheSAScabletotheSAS-OUTportandtheothertotheSAS-INportofanother

RX1213sas,orviceversa.FormoreinformationabouthowtostartupRS10613xs+,

pleaserefertotheQuickInstallationGuidethatcomeswithyourRackStation.
