12
Chapter2:SettingUp
3
TurnonthepowersupplylocatedonthebackofbothRS10613xs+and
RX1213sas("-").
RS10613xs+
RX1213sas
RX1213sas
The Expansion Unit ID of RX1213sas connected to RS10613xs+
will be displayed here in sequence.
Note:
EvenwithRS10613xs+poweredoff,RX1213saswillstillbepoweredonifthe
powersupplyunit(s)isturnedon.TopoweroffRX1213sas,pleaseshutdownthe
powerofRS10613xs+rst,thenmanuallyturnoffRX1213sas'powersupplyunits.
