1
3
ThankyouforpurchasingthisSynologyRX1213sasexpansionunit.This
productisspeciallydesignedtoexpandthestoragecapacityofaSynology
RackStation.Inthechaptersbelow,we'llprovideinstructionstosetupand
startusingthisexpansionunit.
PackageContents
Beforestarting,pleasecheckthepackagecontentstoverifythatyouhave
receivedtheitemsbelow.
Expansion unit x 1 AC power cord x 2
User’s guide x 1
Screws for 3.5”
drives x 52
Screws for 2.5”
drives x 52
SAS cable x 2
Getting Started
