Lainox CEV026S+LD25 [2/5] Cev 026 s tav a

ed. 0713

ATTENZIONE: PER ORDINARE I RICAMBI, SPECIFICARE SEMPRE IL MODELLO DI FORNO ED IL NUMERO DI MATRICOLA

ATTENTION: WHEN ORDERING SPARE PARTS, PLEASE ALWAYS SPECIFY THE OVEN MODEL AND THE SERIAL NUMBER

ATTENTION: POUR COMMANDER DES PIECES, MERCI DE SPECIFIER TOUJOURS LE MODELE DU FOUR ET LE NUMERO DE SERIE

ACHTUNG: UM ERSATZTEILE ZU BESTELLEN, BITTE IMMER OFEN-MODELL UND SERIENNUMMER GEBEN.

POS. COD. Pz. DESCRIZIONE DESCRIPTION DESCRIPTION BESCHREIBUNG DESCRIPCIÓN

1 R18211840 1 ASS.CERNIERA INF. PORTA CEV

LOWER DOOR HINGE CHARNIERE INFERIEURE PORTE UNTERES SCHARNIER BISAGRA INFERIOR

2 R10201700 1 ASS.FILTRO DI SCARICO D.76/44.5 M/106-11 DRAIN FILTER FILTRE ENCEINTE ABFLUSSFILTER FILTRO DESAGUE

3 R65321290 1 ASS.TAPPO PER PRESA USB 2012 COVER FOR USB BOUCHON POUR USB ABDECKUNG TAPON PARA USB

4 R65090300 1 ATTUATORE (G01002230V) MAGNETIC SPOOL BOBINE MAGNÉTIQUE MAGNETISCHE SPULE BOBINA MAGNÉTICA

5 R65321250 1 BOCCOLA PER PRESA USB 2012 BUSH DOUILLE BUSCH CASQUILLO

6 R18424150 1 CERNIERA SUPERIORE PORTA CEV UPPER DOOR HINGE CHARNIERE SUPERIEURE PORTE OBERES SCHARNIER BISAGRA SUPERIOR

7 R65140730 1

CONT.AUS.1L+1R DILM32-XHI11 4-7,5KW

MOE.

AUX.CONTACT CONTACT AUXILIAIRE ZUSÄTZLICHER KONTAKT CONTACTO AUXILIAR

8 R62280028 1

CURVA C/MORSET.HTS-HTSW X TUBOD.40

D.40X

CURVE WITH TERMINAL COURBE AVEC BORNIER KURVE MIT KLEMM CURVA CON REGLETERA

9 R58004050 2 DADO PER PERNO CERNIERA REG. M/106-220 NUT FOR UPPER DOOR HINGE ECROU CHEVILLE CHARNIERE SUPERIEURE MUTTER F. OBERES SCHARNIERSTIFT TUERCA PARA PERNO BISAGRA SUPERIOR

10 R58004380 1 DADO PER PRESA USB 2012 NUT ECROU MUTTER TUERCA

11 R65110200 1 E.V. 1 VIA 220V 50HZ X J.G. CON ATTACC SOLENOID VALVE 220V 50HZ ELECTROVANNE 220V 50HZ MAGNETVENTIL 220V 50HZ ELECTROVALVULA 220V 50HZ

12 R65110230 1

E.V. 2VIE 1P+1D 220V/50HZ J.G. CON

ATTACC

SOLENOID VALVE ELECTROVANNE MAGNETVENTIL ELECTROVALVULA

13 R65280450 1 FERRITE TRCN 28-16-20 PASSANTE FERRITE FERRITE FERRIT FERRITA

14 R70010050 1 GUARNIZIONE OR 7,60 X 2,62 OR 3030 NB

JOINT OR 7,60x2,62 OR GASKETS RINGDICHTUNG 7,60X2,62 JUNTA OR 7,60x2,62

15 R70020020 1 GUARNIZIONE DI TENUTA A 04 BAD40 8X22 JOINT GASKETS RINGDICHTUNG JUNTA

16 R70010250 1 GUARNIZIONE OR 17,17 X 1,78 NBR-70 JOINT OR 17,17 X 1,78 OR GASKETS RINGDICHTUNG 17,17 X 1,78 JUNTA OR 17,17 X 1,78

17 R70050130 1 GUARNIZIONE TUBO SFIATO D.50 JOINT GASKETS RINGDICHTUNG JUNTA

18 R62030118 1

MANICOTTO RIDUZ.F.1/8-1/4 CIL.

PRDI222100

1/8"-1/4" FEMALE REDUCTION COUPLING MANCHON REDUCTION 1/8" - 1/4" REDUZIERMUFFE 1/8" - 1/4" F

MANGUITO REDUCCION HEMBRA 1/8”-

1/4”

19 R70060080 1 MANICOTTO SILICONE D.13X18X80 SILICON SLEEVE SILICONE SLEEVE

SILIKONHÜLLE

FUNDA DE SILICONA

20 R69030280 2 MANOPOLA ENCODER D.42 BLU FA 6264 KNOB KIT POIGNEE COMMANDE DREHKNOPF PULSADOR MANETA

21 R75300030 1 MASCHERINA VENTILATORE D.190

FAN GUARD GRID D.190 GRILLE VENTILATEUR D.190 VENTILATORSCHUTZGITTER D.190 REJILLA VENTILADOR D.190

22 R65260540 1 MICRO PORTA DOOR SWITCH MICRO PORTE TUERSCHALTER MICRO PUERTA

23 R65220091 1 MORSETTIERA LX2E (TIPO 2) NEW TERMINAL BOARD BORNIER KLEMMLEISTE REGLETERA

24 R65041040 1

MOTORE 1F.125Win-75Wout 2VEL C/COND.

FIR

MOTOR MOTEUR MOTOR MOTOR

25 R69010260 1 NASELLO 1 STEP 6303-020022 DOOR LATCH 1 STEP GACHE DE PORTE POUR OUVERTURE SIMPLE SCHLIESSNASE 1 STUFE NARIZ 1 CIERRE

26 R58002670 1 PERNO INF.CERNIERA REG.C/FERMI SR.2005 LOWER HINGE PIN CHEVILLE CHARNIERE INFERIEURE UNTERES SIE SCHARNIERSTIFT PERNO INFERIOR BISAGRA

27 R58002150 1 PERNO SUP.CERNIERA REG. M/106-220 UPPER HINGE PIN CHEVILLE CHARNIERE SUPERIEURE OBERES SCHARNIERSTIFT PERNO SUPERIOR BISAGRA

28 R58001850 8 PERNO SUPP. PARATIE M5 MIXTER RACK HOLDER BOLZEN AUFLAGESCHIENEN SUPPORT GLISSIERE PERNO SOPORTE MAMPARO

29 R65210020 3 PORTAFUSIBILE BARRA DIN 5x20 FUSE CARRIER PORTE-FUSIBLE SICHERUNGSHALTER PORTAFUSIBLE

30 R65270510 1

PORTALAMPADA STAGNO ALPHATECH

77.705.U10

WATERPROOF LIGHT SOCKET DOUILLE ETANCHEE DICHTE LAMPEHALTERUNG PORTALAMPARA ESTANCO

31 R65240010 1 PRESSACAVO PG 107 Z/16 FAIRLEAD PRESSE CABLE ZUGENTLASTUNG PRENSACABLES

32 R63070050 1 PRESSOSTATO 1/8" 0,5-0,35 BAR PH/91140 WATER SAFETY PRESSURE SWITCH INT.A PRESSION SEC.-EAU WASSER-DRUCKWACHTER PRESOSTATO AQUA

33 R62090478 2

RACC. INTERMEDIO A GOMITO D.10

PM0310E

ELBOW PIPE FITTING COURBE AVEC QUEUE STUCK MIT SCHAFT RACOR CON CODO

34 R62090458 2 RACC. INTERMEDIO DIRITTO D.10 PM0410E PIPE FITTING COURBE STUCK RACOR

35 R62090528 1

RACC.A GOMITO C/CODOLO 10X10

PM221010E

ELBOW PIPE FITTING (WITH TANG) 10X10 COURBE AVEC QUEUE 10X10

WINKELVERBINDUNGSSTUCK 10X10 MIT

SCHAFT

Racor CON CODO 10X10

36 R62090508 1

RACC.TERMIN.DIR.FIL.CON.10X1/4

PM011002E

10X1/4 STRAIGHT THREADED TERMINAL PIPE

FITTING

RACCORDEMENT

ENDVERBINDUNGSSTUCK 10 X 1/4" GESCH-

NITTEN

RACOR

37 R65170100 2 RELE' FINDER 628282300309PSA RELAY RELAIS RELAIS RELE

38 R65011670 1

RESISTENZA 5000W230V CAM. DOPPIO

ANELLO

HEATING ELEMENT RESISTANCE HEIZKOERPER RESISTENCIA

CEV 026 STAV. A
