Lainox CEV026S+LD25 [3/5] Cev 026 s tav a

ed. 0713

ATTENZIONE: PER ORDINARE I RICAMBI, SPECIFICARE SEMPRE IL MODELLO DI FORNO ED IL NUMERO DI MATRICOLA

ATTENTION: WHEN ORDERING SPARE PARTS, PLEASE ALWAYS SPECIFY THE OVEN MODEL AND THE SERIAL NUMBER

ATTENTION: POUR COMMANDER DES PIECES, MERCI DE SPECIFIER TOUJOURS LE MODELE DU FOUR ET LE NUMERO DE SERIE

ACHTUNG: UM ERSATZTEILE ZU BESTELLEN, BITTE IMMER OFEN-MODELL UND SERIENNUMMER GEBEN.

CEV 026 STAV. A

POS. COD. Pz. DESCRIZIONE DESCRIPTION DESCRIPTION BESCHREIBUNG DESCRIPCIÓN

39 R65302300 1 SCHEDA "S" COMPACT 2009 ORIZZ. COMPLETA CONTROL PANEL P.C. BOARD "S" MOD FICHE PANNEAU COMMANDES "S" TASTATURPLATINE "S" PLACA PULSADORES "S"

40 R65302280 1 SCHEDA BASE "S" COMPACT 2009 MAIN PC BOARD "S" MOD FICHE PANNEAU PRINCIPAL "S" HAUPTPLATINE "S" PLACA BASE "S"

41 R65302460 1 SCHEDA TASTIERA "S" COMPACT ORIZZ. RELAY PC BOARD "S" MOD FICHE PANNEAU COMMANDES "S" TASTAURPLATINE "S" PLACA PULSADORES "S"

42 R65301941 1 ENCODER "S" COMPACT 2009 "SANDWICH" FRONT PC BOARD ENCODER ENCODER PLATINE ENCODER F. PLATINE ENCODER PLACA ELECTRONICA

43 R65302450 1 SCHEDA BUZZER FORNO "S" LAINOX BUZZER BOARD SONNERIE PANNEAU PLATINE MIT ZEITGLEID PLACA ZUMBADOR

44 R65321102 1 SONDA AL CUORE K 4 PUNTI 6 PIN.IMP.2012 CORE TEMPERATURE PROBE SONDE A COEUR KERNTEMPERATURFUEHLER SONDA AL CORAZON

45 R65321110 1 CONNETTORE FEMM. S/CUORE 6 PIN

CORE TEMPERATURE PROBE FEMALE CON-

NECTOR

CONNECTEUR FEMELLE POUR SONDE A

COUER

STECKDOSE F. KERNTEMPERATURFUEHLER

CONECTOR HEMBRA PARA SONDA AL

CORAZON

46 R65321020 1 TAPPO X CONNETTORE 4 PIN. COVER FOR CONNECTOR BOUCHON POUR CONNECTEUR ABDECKUNG STECKDOSE TAPON PARA CONECTOR

47 R86020400 1

VALIGETTA X SONDA AL CUORE TRASPA-

RENTE

CORE TEMPERATURE PROBE BOX PETITE VALISE SONDE A COEUR TASCHE F. KERNTEMPERATUFUEHLER ESTUCHE DE SONDA AL CORAZON

48 R65320220 2

SONDA "K" 6X80 1,5ML. TESTA

RASTREM.20mm

PROBE "K" 6X80 1,5ML. SONDE "K" 6X80 1,5ML. FUEHLER "K" 6X80 1,5ML. SONDA "K" 6X80 1,5ML.

49 R62100108 1 TAPPO ROSSO D.10 (PM0810R) RED COVER BOUCHON ABDECKUNG TAPON

50 1 TASTIERA PLATE PLAQUE BEDIENUNGSFOLIE TARJETA

51 R70044890 1 TELAIO GUARN. PORTA CEV 061-026 FRONT GASKET JOINT FACADE DICHTUNG DER FRONTSEITE JUNTA FRONTAL

52 R65140700 3 TELERUTTORE DIL M9-01 4KW-20A MOELLER CONTACTOR CONTACTEUR SCHUETZ CONTACTOR

53 R65070350 1 TERMOSTATO SICUR. 360øC -25K 55.32572.8 THERMOSTAT THERMOSTAT THERMOSTAT TERMOSTATO

54 R65180420 1 TRASF.RE 20VA 0-220-240/12V MOD.163.16 TRANSFORMER TRANSFORMATEUR TRANSFORMATOR TRANSFORMADOR

55 R80150000 1m TUBO PE 10MMX7 AZZURRO PM950612E PE D.10 MM X7 WATER FLEXIBLE PIPE TUBE FLEXIBLE EAU D. 10x7 WASSERFLEXROHRLEITUNG PE D.10MMX7 TUBO FLEXIBLE AGUA PE D.10mm X 7

56 R58006160 1 UGELLO COND.D.0,8 CODOLO CIL.10 NOZZLE BEC DÜSE BOQUILLA

57 R65060050 1 VENTILATORE COMPATTO D.120 4715MS 23T COMPONENTS VENTILATION MOTOR MOTEUR DE REFROIDISSMENT ABKULUNGS MOTOR MOTOR DE ENFRIAMIENTO

58 R65060010 1 VENTILATORE COMPATTO D.80 TP.W2S 076 COMPONENTS VENTILATION MOTOR MOTEUR DE REFROIDISSMENT ABKULUNGS MOTOR MOTOR DE ENFRIAMIENTO

59 R75400580 1 VENTOLA D.200X50 50HZ P.D. FAN TURBINE LUEFTERRAD PALA VENTILADOR

60 R18105420 1 PORTA COMPLETA CEV061-026 LX DOOR ASSEMBLY PORTE COMPLETE TUER KOMPLETT PUERTA COMPLETA

61 R58005500 1 FLANGIA GUARNIZIONE MOTORE MOTOR GASKET BRASS FLANGE BRIDE JOINT MOTEUR FLANSCH F. MOTORDICHTUNG BRIDA JUNTA MOTOR

62 R65110500 1 REGOL. PORT. MARR. ATCH. 10Lt/h 10 LT/H WATER FLOW REDUCER REGULATUER DE DEBIT 10 LT. DURCHFLUSSMONDERER 10L/STD. REGULADOR DE CAUDAL 15 LT.

63 R65190080 1 CONDENSATORE 5µF CAPACITOR CONDENSATEUR KONDENSATOR CONDENSADOR

P1 R18211820 1 PORTA ESTERNA CEV061-026 EXTERNAL DOOR PORTE D'EXTERNAL AUSSENTÜR PUERTA EXTERNA

P2 R71200951 1 VETRO POST. PORTA CEV061 435x465x6 B.E. DOOR GLASS VITRE PORTE HARTGLASS VIDRIO PUERTA

P3 R58001780 2 FERMO VETRO PORTA P2000 INNER GLASS CATCH KIT ENSEMBLE ARRET VERRE INTERIEUR VERSCHLUSSATZ F. INNENSCHEIBE KIT FIJACION VIDRIO INTERNO

P4 R61620152 1 MOLLA AGGANCIO NASELLO CORTA DOOR LOCK SPRING RESSORT DE FERMETURE PORTE TÜR SCHLUSSFEDER MUELLE DE ENGANCHE A TRINQUET

P5 R18404520 2 SPESSORE PROTEZIONE VETRO

THICKNESS EPAISSEUR DICKE ESPESOR

P6 R11423460 2 PROTEZIONE VETRO PORTA K E T 2011 GLASS PROTECTION PROTECTION DE VERRE GLASSCHUTZ PROTECCION VIDRIO

P7 R58001760 2 CERNIERA FISSA VETRO SR2000 INNER GLASS SOLID HINGE CHARNIERE VERRE INTERIEUR SCHARNIER F. INNENSCHEIBE BISAGRA FIJA VIDRIO INTERNO

P8 R58001770 2 PERNO CERNIERA VETRO SR2000 INNER GLASS HINGE PIN PIVOT CHARNIERE VERRE INTERIEUR SCHARNIERBOLZEN F. INNENSCHEIBE PERNO BISAGRA VIDRIO INTERNO

P9 R70050100 6 TASSELLO BATTUTA VETRO SR.2000 GLASS SILICON SPACERS GOUJON SILICONIQUE ARRETE-VITRAGE PORTE SILIKONANSCHLAG F. INNENSCHEIBE TOPE GOLPE VIDRIO

P10 R58001860 1 PERNO SUPP. PARATIE ALPHATECH RACK HOLDER SUPPORT GLISSIERE BOLZEN AUFLAGESCHIENEN PERNO SOPORTE MAMPARO

P11 R69010290 1

GRUPPO CHIU.BASC.C/AN.CROM.6303-

BLU-CORT

DOOR CATCH KIT ENSAMBLE FERMETURE PORTE VERSCHLUSSATZ MANIJA DE LA PUERTA

P12 R18211890 1 ASS.COPERTURA MANIGLIA PORTA CEV DOOR HANDLE POIGNEE DE PORTE GRIFFKORPUS CUERPO MANETA
