REMOVING THE CUTTING TOOLS
Raise the pusher plate (1:A) and swing it out to the
left, or remove the feed hopper (1:N).
Turn the locking knob (1:B) anti-clockwise and
raise the feed cylinder (1:C) alternatively (1:O).
Remove the drilling sleeve (1:J) alternatively the
stirring sleeve (1:M) by turning it clockwise by
means of the spanner (1:K).
Remove the cutting tool/tools and the ejector
plate (1:D).
USING THE FEEDERS
Feed cylinder with push feeder:
The large feed compartment is used mainly for
bulk feeding of most kinds of products (2:C) and
for cutting larger products such as cabbage.
The large feed compartment is also used when the
material is to be cut in a definite direction, such as
tomatoes and lemons. Place/stack the products as
shown in the figure (3:D).
The feed tube is used for cutting long products
such as cucumbers (3:E).
Feed cylinder with feed hopper:
The feed hopper (3:C) is used for continuous
feeding/cutting of large quantities of potatoes,
onions, dry bread, nuts, mushrooms, etc.
CLEANING
Switch off the machine and remove the power
supply plug from the socket.
Carefully clean the machine immediately after use.
If the cutting tools are marked "diwash", read and
follow the special "diwash" user instruction manual
carefully.
Never wash light metal items in the dishwasher
unless they are marked “diwash”.
If you have used a dicing grid (2:G), leave it in the
machine, and use the brush (3:B) for pushing out
any dices remaining in the grid.
Remove the loose parts of the machine, wash
them and dry them thoroughly.
Wipe the machine with a damp cloth.
Always wipe the knives of the cutting tools dry
after use.
Always store the cutting tools (2) on the hangers
(3:A) on the wall.
Never use sharp objects or a high-pressure spray
gun for cleaning.
Never spray water on the sides of the machine.
CHECK EVERY WEEK
That the machine stops as soon as the pusher
plate (1:A) has been moved up and swung out, and
that it restarts when the pusher plate has been
swung in and lowered.
That the machine cannot be started with the feed
cylinder (1:C) removed and with the pusher plate
lowered.
That the machine cannot be started with the feed
cylinder (1:O) fitted but the feed hopper (1:N)
removed.
Remove the plug from the power supply socket
and then check that the electric cable is in good
condition and is not cracked on the outside.
If any of the safety functions does not perform as
intended or if the electric cable is cracked, get a
specialist to attend to the machine before
connecting it back to the power supply.
Check that the pusher plate shaft (1:I) has been
lubricated as necessary and runs freely. If the shaft
does not run freely, clean it carefully and lubricate
it with a few drops of machine oil.
Check that the knives and shredder plates are in
good condition and are sharp.
TROUBLE-SHOOTING
FAULT: The machine cannot be started, or stops
while it is running and cannot be restarted.
REMEDY: Check that the plug is securely fitted
into the power supply socket, or that the isolating
switch is closed. Check that the feed cylinder (1:C)
alternatively (1:O), pusher plate (1:A) or the feed
hopper (1:N) is locked in the correct position.
Move down the pusher plate into the feed
cylinder. Check that the fuses in the fuse box for
the premises have not blown and that they have
the correct rating. Wait for a few minutes and try
to restart the machine. If the machine still fails to
run, call a specialist.
FAULT: Low capacity or poor cutting results.
REMEDY: Make sure that you are using the
correct cutting tool or combination of cuttings
tools (2). Fit the drilling sleeve (1:J) alternatively the
stirring sleeve (1:M). Check that the knives and
shredder plates are in good condition and are
sharp. Press the food down loosely.
FAULT: The cutting tool (2) cannot be removed.
REMEDY: Always use the ejector plate (1:D). Use a
thick leather glove or the like that the knives of
the cutting tool cannot cut through, and turn the
cutting tool clockwise to release it.
FAULT: The drilling sleeve (1:J) alternatively the
stirring sleeve (1:M) cannot be removed.
REMEDY: Use the spanner (1:K) to unscrew the
drilling sleeve (1:J) alternatively the stirring sleeve
(1:M) clockwise.
TECHNICAL SPECIFICATION
MACHINE: Motor: 0.75 kW, 230 V, single-phase,
50 Hz, or 400 V, 3-phase, 50 Hz, with thermal
motor protection. Transmission: gears. Safety
system: Four safety switches. Degree of
protection: IP44. Power supply socket: Earthed,
single-phase, 10 A, or 3-phase, 16 A. Fuse in fuse
box for the premises: 10 A, slow-blow. Sound
level LpA (EN31201): 73 dBA.
TOOLS: Diameter: 215 mm. Speed: 360 rpm.
MATERIALS: Machine housing and feed cylinder:
Anodized or polished aluminium alloy and/or
stainless steel. Cutting tool discs: Aluminium alloy.
Cutting tool knives: Knife steel of the highest
quality.
NET WEIGHTS: Machine base: 26 kg. Feed
cylinder with push feeder: 6 kg. Feed cylinder with
feed hopper: 7,5 kg. Cutting tools: About 1 kg on
average.
STANDARDS: NSF STANDARD 8 for machine,
EU Machine Directive 89/392EEC.
